Allen-Bradley 1784-PKTS PLC-5 Network Interface Card

Allen-Bradley 1784-PKTS PLC-5 Network Interface Card

Description

The Allen-Bradley 1784-PKTS is a high-performance network interface card designed for integration with PLC-5 systems. This PCI-bus compliant module serves as a bridge, enabling robust communication between industrial computing platforms...

18 people are viewing this right now

Availability: In stock

SKU: 1784-PKTS
Vendor: Allen-Bradley
Category: Network Interface Card
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1784-PKTS is a high-performance network interface card designed for integration with PLC-5 systems. This PCI-bus compliant module serves as a bridge, enabling robust communication between industrial computing platforms and Remote I/O (RIO) networks. As a specialized interface card, it provides the necessary hardware layer for reliable data exchange in demanding automation environments.

Features

  • PCI Bus interface compatible with both 5V and 3.3V universal slots.
  • Integrated RIO (Remote I/O) scanner functionality for streamlined network management.
  • Single-channel communication architecture.
  • Standard PCI form factor for easy installation into industrial workstations.
  • BNC (Twinax) connector type for secure network cabling.
  • Galvanic isolation rated at 1500V AC to protect sensitive system components.

Technical Specifications

Product Model 1784-PKTS
Bus Interface 32-bit PCI (5V or 3.3V Universal)
Power Consumption 1.8W typical
Isolation Voltage 1500V AC
Connector Type BNC (Twinax)
Operating Temperature 0 degC to +60 degC
Storage Temperature -40 degC to +85 degC
Humidity 5-95% non-condensing

Installation Guidelines

  • Ensure the host system is powered down before inserting or removing the 1784-PKTS card from the PCI slot.
  • Handle the card by the edges to prevent electrostatic discharge (ESD) damage to sensitive electronic components.
  • Verify that the PCI slot is a 32-bit configuration to ensure proper bus communication.
  • Proper termination is required for network integrity; ensure 75-ohm resistors are utilized as specified for the RIO network.
  • Maintain adequate airflow within the chassis to keep the operating temperature within the 0 degC to +60 degC range.

FAQ

Is the 1784-PKTS still in production?
No, this model has been discontinued by the manufacturer. We provide high-quality surplus units for maintenance and legacy system support.

What type of cable connection does this card use?
The 1784-PKTS utilizes a BNC connector for Twinax cabling, which is standard for RIO network configurations.

Does this card require specific termination?
Yes, the network requires 75-ohm resistors for proper termination to ensure signal integrity and prevent data reflection on the RIO line.
