Allen-Bradley 1734-IB8 POINT I/O 8-Point Digital Input Module

Allen-Bradley 1734-IB8 POINT I/O 8-Point Digital Input Module

Description

The Allen-Bradley 1734-IB8 is a high-density digital input module designed for the POINT I/O platform. This module provides 8 sinking digital inputs, operating at a nominal 24V DC. It is...

16 people are viewing this right now

Availability: Low stock: 1 left

SKU: 1734-IB8
Vendor: Allen-Bradley
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1734-IB8 is a high-density digital input module designed for the POINT I/O platform. This module provides 8 sinking digital inputs, operating at a nominal 24V DC. It is engineered for space-constrained industrial environments, offering reliable signal monitoring and integration within Rockwell Automation control systems.

Features

  • 8-point sinking digital input configuration.
  • Compact design suitable for distributed I/O applications.
  • Integrated status indicators for both module health and individual input status.
  • Compatible with 1734-TB or 1734-TBS wiring base assemblies.
  • Low power dissipation of 1.6 Watts.

Technical Specifications

Manufacturer Allen-Bradley (Rockwell Automation)
Module Type Digital DC Sinking Input
Input Voltage 24V DC (Range: 10-28.8V DC)
Number of Inputs 8
Nominal Input Current 4mA @ 24V DC
POINTBus Current 75 mA
Power Dissipation 1.6 Watt / 5.5 BTU/hour
Keyswitch Position 1
Enclosure Rating Open-style

Installation Guidelines

  • Ensure the system power is disconnected before installing or removing the module from the POINTBus.
  • The 1734-IB8 must be mounted on a compatible 1734-TB or 1734-TBS wiring base assembly.
  • Verify the keyswitch position is set to 1 to ensure proper mechanical alignment and protection.
  • Maintain proper grounding and shielding practices for input signal wiring to minimize EMI interference.
  • Ensure adequate ventilation within the control cabinet to maintain operating temperatures within specified limits.

FAQ

What is the input type for this module?

The 1734-IB8 is a sinking digital input module, meaning it is designed to accept inputs that sink current to the common return.

Which wiring bases are compatible with the 1734-IB8?

This module is designed to be installed on 1734-TB or 1734-TBS wiring base assemblies.

What does the status indicator on the module signify?

The module features a bi-color (green/red) status indicator on the logic side for module health, and 8 yellow indicators to monitor the status of each individual input channel.
