Allen-Bradley GU-D15 80173-110-01 Gate Commutated Turn-Off Board

Allen-Bradley GU-D15 80173-110-01 Gate Commutated Turn-Off Board

Description

The Allen-Bradley GU-D15 (80173-110-01) is a Gate Commutated Turn-Off (GCT) board designed for use within PowerFlex drive systems. This power electronics component is engineered to facilitate precise switching control, ensuring...

17 people are viewing this right now

Availability: Low stock: 6 left

SKU: GU-D15 80173-110-01 G651885A H011203-28
Vendor: Allen-Bradley
Category: Gate Commutated Turn-Off Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley GU-D15 (80173-110-01) is a Gate Commutated Turn-Off (GCT) board designed for use within PowerFlex drive systems. This power electronics component is engineered to facilitate precise switching control, ensuring reliable operation of the drive's power stage. It is compatible with specific PowerFlex drive configurations requiring this gate control architecture.

Features

  • Designed for high-performance gate commutation in industrial drive applications.
  • Wide input voltage range supporting global power standards (85 - 264 VAC).
  • Robust thermal operating range suitable for demanding industrial environments.
  • Integrated power regulation providing stable 24 VDC output.

Technical Specifications

Model GU-D15 80173-110-01 G651885A H011203-28
Input Voltage Range 85 - 264 VAC
Frequency Range 47 - 63 Hz
Input Current 1.8 A at 115 VAC
Output Voltage 24 VDC
Nominal Output Current 5.0 A
Nominal Output Power 120 W
Operating Temperature -25 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Relative Humidity 5% to 95% (non-condensing)

Installation Guidelines

  • Ensure the drive system is fully de-energized and locked out before attempting to install or replace the GCT board.
  • Handle the board by the edges to prevent electrostatic discharge (ESD) damage to sensitive gate-drive circuitry.
  • Verify that the board is securely seated in the designated slot to ensure proper electrical contact with the drive backplane.
  • Ensure adequate airflow within the drive cabinet to maintain the specified operating temperature range.
  • Check all cable connections for secure fitment and verify that no debris or conductive dust is present in the mounting area.

FAQ

What is the function of the GU-D15 board?

The GU-D15 is a Gate Commutated Turn-Off board used in Allen-Bradley PowerFlex drives to manage the switching of power semiconductors, which is essential for the drive's motor control and power conversion functions.

Is this board compatible with other models?

This unit is often associated with spare model 80173-110-02. Please verify your specific drive's hardware revision and manual to ensure full compatibility before installation.
