Analog Input Module Yokogawa AAI143-S00

Analog Input Module Yokogawa AAI143-S00

Product Description

The Yokogawa AAI143-S00 is a high-density, 16-channel analog input module engineered for precise current signal acquisition in distributed control systems. It is designed to interface seamlessly with both 2-wire and 4-wire transmitters, offering channel-level flexibility through pin-based...

15 people are viewing this right now

Availability: Low stock: 99 left

SKU: AAI143-S00
Vendor: Yokogawa
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The Yokogawa AAI143-S00 is a high-density, 16-channel analog input module engineered for precise current signal acquisition in distributed control systems. It is designed to interface seamlessly with both 2-wire and 4-wire transmitters, offering channel-level flexibility through pin-based configuration. With its robust galvanic isolation and high-speed data update period, this module ensures accurate process monitoring in mission-critical automation environments. The unit includes an integrated transmitter power supply, simplifying field wiring while maintaining strict adherence to industrial signal integrity standards.

Technical Specifications

Specification Details
Model AAI143-S00
Input Channels 16 isolated channels
Signal Type 4 to 20 mA DC
Allowable Input Current 24 mA
Accuracy ±16 μA
Data Update Period 10 ms
Transmitter Power Supply 19.0 V (at 20 mA) to 25.5 V (at 0 mA)
Input Resistance (Power ON) 270 Ω (20 mA) to 350 Ω (4 mA)
Withstanding Voltage 1500 V AC for 1 minute (Input to System)
Power Consumption 230 mA (5 V DC) and 540 mA (24 V DC)
Ambient Temperature Drift ±16 μA per 10 °C
Dimensions 13 cm x 3 cm x 13 cm
Weight 0.2 kg

Operational Advantages

Designed for versatile field integration, the AAI143-S00 supports selectable 2-wire or 4-wire transmitter setups for each individual channel. This granular control allows for complex instrumentation layouts within a single module rack. Its high input impedance when powered off (500 kΩ or larger) protects the internal circuitry from accidental damage during maintenance, while the internal current limit of 25 mA provides essential loop protection against short-circuit conditions.

Frequently Asked Questions

Q: How do I configure the channel for a 2-wire vs 4-wire transmitter?

A: The configuration is performed using physical settings on the module's pins for each individual channel, allowing for mixed-signal setups within the same unit.

Q: Does the module provide power to field transmitters?

A: Yes, it includes an integrated transmitter power supply designed to provide up to 25 mA output current, sufficient for standard loop-powered field instruments.
