AVR10D-0022020 Dual-Redundant V-net Router Yokogawa

AVR10D-0022020 Dual-Redundant V-net Router Yokogawa

The Yokogawa AVR10D-0022020, also cataloged as the AVR10D Dual-Redundant V-net Router, operates as a dedicated hardware component for high-speed network communication and packet routing within CENTUM system platforms. This unit...

15 people are viewing this right now

Availability: Low stock: 50 left

SKU: AVR10D-0022020
Vendor: Yokogawa
Category: Dual-Redundant V-net Router
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Yokogawa AVR10D-0022020, also cataloged as the AVR10D Dual-Redundant V-net Router, operates as a dedicated hardware component for high-speed network communication and packet routing within CENTUM system platforms. This unit provides direct physical execution of inter-network data exchange, managing dual-redundant paths to ensure constant connectivity across DCS control domains.

Suffix Breakdown & Model Matrix

Suffix Code Specification
AVR10D Base Dual-Redundant V-net Router
-0022020 Configuration variant defining power and interface parameters

Hardware Specifications

Parameter Specification
Model AVR10D-0022020
Brand Yokogawa
Origin Japan
Weight 2.5 kg
Dimensions 210 mm (W) x 230 mm (H) x 80 mm (D)
Operating Temp -10 deg C to +55 deg C
Power Consumption 20 W
Vnet/IP Interface 100 Mbps, Full-duplex, RJ45
Vnet Interface 10 Mbps, BNC connector

DCS Instrumentation and Communication

The AVR10D-0022020 facilitates seamless bridge connectivity between standard Vnet serial-based communication and Vnet/IP high-speed networks. The module supports full-duplex transmission over RJ45 interfaces and dual-redundant BNC connections, ensuring data packets are routed without loss during master node transitions. Galvanic isolation at the communication ports is maintained to protect sensitive internal components from electrical disturbances common in large-scale plant network infrastructures.

Frequently Asked Questions

Q: Does this router support hot-swapping while the network is active?

A: No, power must be disconnected from the redundant supply terminals before physically removing or replacing the router to prevent disruption of the communication bus.

Q: Is the Vnet interface compatible with single-cable configurations if redundancy is not required?

A: Yes, the BNC interface supports both single and dual-redundant cable topologies; unused ports must be properly terminated to prevent signal reflection.

Field Installation Guidelines

  • Mount the unit vertically within the control cabinet to maximize heat dissipation from the 20 W power load and ensure ambient air circulation.
  • Ensure all BNC cable connections are seated firmly and shielded correctly to maintain 10 Mbps transmission stability.
  • Verify that the input voltage for the redundant power supplies is within the 100-120 V AC or 220-240 V AC range before energizing the system.
  • Maintain a minimum distance of 50 mm from high-voltage cables to prevent electromagnetic noise from interfering with the Vnet/IP signal.
  • Ground the chassis of the AVR10D-0022020 to the cabinet common earth bar to ensure system-wide electrical noise immunity.
