Bachmann DIO216/4 M1 System Digital Input Output Module

Bachmann DIO216/4 M1 System Digital Input Output Module

Product Description

The DIO216/4 is a versatile digital signal processing module for the Bachmann M1 automation system, providing a high-density mixed I/O interface within a single hardware footprint. Designed for industrial resilience, it incorporates optocoupler-based electrical isolation to protect...

25 people are viewing this right now

Availability: Low stock: 99 left

SKU: DIO216/4
Vendor: Bachmann
Category: Digital Input/Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The DIO216/4 is a versatile digital signal processing module for the Bachmann M1 automation system, providing a high-density mixed I/O interface within a single hardware footprint. Designed for industrial resilience, it incorporates optocoupler-based electrical isolation to protect the central processor from voltage spikes and electromagnetic interference. This makes the DIO216/4 a reliable choice for precision machine control and plant automation applications.

Technical Specifications

Specification Details
Primary Identification DIO216/4
Manufacturer Bachmann Electronic GmbH
I/O Configuration 16 digital channels (configurable / mixed I/O)
Input Voltage Range 24 VDC (nominal)
Switching Logic PNP / Sink supported
Signal Isolation Optocoupler isolation between bus and process levels
Physical Footprint (H × W × D) 5.3 cm × 11.7 cm × 7.1 cm
Net Weight 0.30 kg

Application Utility

  • High-Speed Switching: Conveyor sorting systems and pulse-based detection.

  • Actuator Control: Hydraulic and pneumatic valve actuation.

  • Heavy Machinery: Limit switch and interlock monitoring in high-vibration environments.

  • Marine & Substation Automation: Where signal clarity and mechanical robustness are critical.

The mixed I/O capability reduces total module count, optimizing cabinet space and lowering overall system complexity.

Frequently Asked Questions

Q: Does the DIO216/4 support short-circuit protection on its outputs?
A: Yes. The module includes electronic short-circuit and thermal overload protection to safeguard output stages during field wiring faults.

Q: Can this module be used with 12 V logic signals?
A: No. The DIO216/4 is designed for 24 V industrial logic. Using 12 V signals may lead to unreliable high-state detection; sensor compatibility should be verified prior to integration.
