Backplane Module Bachmann BS206

Backplane Module Bachmann BS206

Product Description

The Bachmann BS206 is a core backplane for the Bachmann M1 Automation System. It provides electrical and mechanical interconnects for M1 components, including processor modules, power supplies, and I/O slices, enabling...

21 people are viewing this right now

Availability: Low stock: 99 left

SKU: BS206
Vendor: Bachmann
Category: Backplane Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The Bachmann BS206 is a core backplane for the Bachmann M1 Automation System. It provides electrical and mechanical interconnects for M1 components, including processor modules, power supplies, and I/O slices, enabling modular scalability and reliable system operation.

Technical Specifications

Parameter Specification
Manufacturer Bachmann Electronic
Model Identifier BS206
Capacity 6 module slots
Mounting Compatibility EN 60715 DIN rail
Mechanical Design Vibration-proof module fixing
Electrical Integration Integrated backplane communication bus
Build Quality Compact industrial-grade framework

Operational Reliability

  • Secure locking mechanism prevents module dislodgement in high-vibration environments

  • Easy snap-on installation onto standard DIN rails

  • Provides stable electrical backbone to minimize signal noise and contact resistance

  • Supports modular expansion for scalable M1 automation systems

FAQ

Does the BS206 provide electrical isolation between slots?
No. Isolation is handled by the individual modules, not the backplane itself.

Can multiple BS206 units be linked?
Yes. Additional backplanes can be connected to expand the system as I/O requirements grow.
