BMXXBE1000 Schneider Modicon X80 Backplane Expander Module

BMXXBE1000 Schneider Modicon X80 Backplane Expander Module

Product Overview

The Schneider Electric BMXXBE1000 is a backplane expansion module for the Modicon X80 platform. It enables communication between local and remote expansion racks, increasing the I/O capacity of...

28 people are viewing this right now

Availability: Low stock: 94 left

SKU: BMXXBE1000
Vendor: Schneider
Category: Backplane Expander Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The Schneider Electric BMXXBE1000 is a backplane expansion module for the Modicon X80 platform. It enables communication between local and remote expansion racks, increasing the I/O capacity of M340 and M580 PLC systems while maintaining stable high-speed data exchange. We supply this unit as 100% brand new and original.

Technical Specifications

Specification Details
Module Type Backplane Expansion Module
Platform Compatibility Modicon X80 (M340 / M580)
Current Consumption 160 mA at 3.3 VDC / 10 mA at 24 VDC
Maximum Rack Support Up to 4 racks
Connection Port 1 × Female Sub-D 9-pin
Mounting Position Dedicated XBE slot
Weight 0.63 kg

Engineering Advantages

Flexible System Expansion
Adds extra I/O racks without changing the CPU.

Space-Saving Installation
Supports distributed cabinet and panel layouts.

Easy Integration
Installs directly into the X80 rack using standard expansion cables.

Stable Communication Performance
Maintains reliable backplane data transfer across multiple racks.

FAQs

Is an expansion module required for each rack?
Yes, each rack requires a BMXXBE1000 for rack-to-rack communication.

Does it require software configuration?
The rack layout must be configured in the software, but the module itself requires no special parameter setup.

What is the maximum cable distance?
The total cable length must not exceed 30 meters.

Is it compatible with both M340 and M580?
Yes, it supports both Modicon M340 and M580 platforms.
