BMXXBE2005 Schneider Electric Modicon X80 Backplane Extender

BMXXBE2005 Schneider Electric Modicon X80 Backplane Extender

Product Overview

The BMXXBE2005 is a backplane expansion kit for the Schneider Electric Modicon X80 platform. It enables expansion of the local I/O bus across multiple racks, supporting scalable configurations...

21 people are viewing this right now

Availability: Low stock: 94 left

SKU: BMXXBE2005
Vendor: Schneider
Category: Backplane Extender
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The BMXXBE2005 is a backplane expansion kit for the Schneider Electric Modicon X80 platform. It enables expansion of the local I/O bus across multiple racks, supporting scalable configurations for Modicon M340 and M580 systems. This allows high-speed communication between the CPU rack and expansion racks. We supply this kit as 100% Brand New and Original for reliable system scalability.

Technical Specifications

Specification Details
Manufacturer Schneider Electric
Product Line Modicon X80
Model Number BMXXBE2005
Product Type Backplane Extender Kit
Kit Contents 2 extender modules + 1 terminal resistor
Compatibility Modicon M340 / M580
Max Racks Supported 4 (1 main + 3 expansion)
Current Consumption 160 mA at 3.3 V DC
Max Distance Up to 30 m (total cable length)
Net Weight 0.63 kg

Engineering Advantages

System Scalability

Allows expansion from a single rack to multi-rack architectures as system requirements grow.

High-Speed Communication

Maintains fast and synchronized X-bus communication across all connected racks.

Clean Cabinet Layout

Dedicated slots ensure organized installation without reducing functional I/O space.

Signal Integrity Protection

Includes terminal resistor to prevent signal reflection and maintain data stability.

Easy Installation

Automatic system recognition reduces configuration time and simplifies commissioning.

FAQs

What is included in the kit?

Two extender modules and one terminal resistor. Expansion cables must be purchased separately.

Is it compatible with M580 systems?

Yes, it is fully compatible with Modicon M340 and M580 X80 architectures.

Is the product brand new?

Yes, it is 100% Brand New and Original in factory-sealed packaging.

How many racks can be connected?

Up to 4 racks total (1 main + 3 expansion), using appropriate extender kits per connection stage.
