CC-MCAR01 51403892-100 Honeywell I/O Carrier Channel

CC-MCAR01 51403892-100 Honeywell I/O Carrier Channel

Product Description

The CC-MCAR01 (51403892-100) is a core structural and electrical component within the Honeywell Experion PKS Series C I/O system. It serves as the carrier channel (mounting backbone) for Input/Output Termination Assemblies (IOTAs) and...

29 people are viewing this right now

Availability: Low stock: 50 left

SKU: CC-MCAR01 51403892-100
Vendor: Honeywell
Category: I/O Carrier Channel
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The CC-MCAR01 (51403892-100) is a core structural and electrical component within the Honeywell Experion PKS Series C I/O system. It serves as the carrier channel (mounting backbone) for Input/Output Termination Assemblies (IOTAs) and associated electronic modules, providing both physical support and internal electrical connectivity for the I/O subsystem.

Engineered for high-density industrial control cabinets, the CC-MCAR01 enables secure vertical mounting of Series C modules while facilitating integrated power distribution and communication pathways to the C300 controller. Its rigid, industrial-grade construction ensures stability under vibration, mechanical stress, and thermal variation in continuous process environments.

By using the CC-MCAR01, IOTAs can be easily installed via snap-in mounting, ensuring reliable connections between field wiring and control hardware while simplifying installation, maintenance, and system expansion.

Technical Specifications

Parameter Specification
Component Type I/O Carrier Channel / Mounting Rail
Product Family Series C I/O
Model Number CC-MCAR01
Part Number 51403892-100
Compatibility Supports all Series C IOTAs and I/O Modules
Mounting Format Vertical Cabinet Mounting
Physical Dimensions 2.2 × 12.4 × 12.6 cm
Net Weight 3.0 kg

Application Scenarios

The CC-MCAR01 is a mandatory structural component in all Honeywell Experion PKS Series C installations. It is used in control rooms and Remote Instrument Enclosures (RIEs) across industries such as petrochemical processing, power generation, and pharmaceuticals.

It provides the foundational mounting structure for building 16-channel and 32-channel I/O racks, enabling organized, scalable, and reliable control system architectures for C300 controllers.

Frequently Asked Questions

How many IOTAs can be mounted on a single CC-MCAR01 carrier?
Typically, one IOTA is mounted per CC-MCAR01 carrier channel. Multiple carriers can be installed side-by-side or in series to form a complete I/O rack or “string” within a control cabinet.

Does the CC-MCAR01 provide electrical grounding?
Yes, when properly installed, the CC-MCAR01 provides a stable grounding path for mounted IOTAs and modules. This grounding is essential for protecting equipment from static discharge and reducing electromagnetic interference.
