CC-PAIX01 PWA Honeywell Analog Input Module

CC-PAIX01 PWA Honeywell Analog Input Module

Product Overview

The Honeywell CC-PAIX01 (51405038-175) is a high-level Analog Input (AI) module for the Experion PKS Series C system. It acquires signals from field transmitters (pressure, temperature, flow) and...

22 people are viewing this right now

Availability: Low stock: 50 left

SKU: CC-PAIX01 PWA
Vendor: Honeywell
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The Honeywell CC-PAIX01 (51405038-175) is a high-level Analog Input (AI) module for the Experion PKS Series C system. It acquires signals from field transmitters (pressure, temperature, flow) and converts 4–20 mA or voltage inputs into high-resolution digital data for the C300 controller.

Supplied as 100% brand new, original factory equipment, it ensures accurate and reliable data acquisition.

Technical Specifications

Parameter Specification
Model Number CC-PAIX01
Input Channels 16 Channels
Resolution 16-bit
Accuracy ±0.1% FS
Input Type 4–20 mA / Voltage
Isolation 1500 VDC
Operating Temp -40°C to 70°C
Weight 0.3 kg
Dimensions 118 × 35 × 104 mm

Engineering Advantages

  • HART Support – Enables digital communication and diagnostics

  • Wide Temperature Range – Suitable for harsh environments

  • High Isolation – Protects system from field disturbances

  • Compact Design – 16 channels in slim form factor

  • High Accuracy – 16-bit resolution for precise measurement

FAQs

Does it support both current and voltage inputs?
Yes, configurable per channel with proper IOTA matching.

How are transmitter faults handled?
Detects open/short circuits and reports alarms to the system.

Is it interchangeable with CC-PAIH01?
Not directly—verify hardware and IOTA compatibility first.

What does “-175” mean?
Indicates conformal coating for harsh environments.
