Communication Module Allen-Bradley 1769-SM1

Communication Module Allen-Bradley 1769-SM1

Product Description

The 1769-SM1 is a communication interface module designed for Allen-Bradley CompactLogix and MicroLogix 1500 controllers. It acts as a gateway between the controller and industrial drives, enabling communication through DPI (Drive Peripheral Interface) or SCANport protocols.

The module...

27 people are viewing this right now

Availability: Low stock: 99 left

SKU: 1769-SM1
Vendor: Allen Bradley
Category: Communication Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 1769-SM1 is a communication interface module designed for Allen-Bradley CompactLogix and MicroLogix 1500 controllers. It acts as a gateway between the controller and industrial drives, enabling communication through DPI (Drive Peripheral Interface) or SCANport protocols.

The module is commonly used with PowerFlex 7-class drives, allowing the controller to exchange control commands and status data with the drive system. It features automatic device detection and baud-rate synchronization, simplifying setup and reducing configuration time.

For reliable operation, the 1769-SM1 must be installed within six slots of the system power supply to maintain stable voltage levels and communication integrity.

Technical Specifications

Parameter Specification
Model 1769-SM1
Compatible Controllers CompactLogix, MicroLogix 1500
Communication Protocols DPI, SCANport
Power Consumption 280 mA @ 5V DC; 60 mA @ 12V DC
Max Distance from Power Supply 6 modules
Operating Temperature -10°C to 50°C (14°F to 122°F)
Dimensions 118 mm × 87 mm × 35 mm
Weight 0.142 kg

Applications

Drive Integration
Enables CompactLogix or MicroLogix controllers to communicate with PowerFlex 7-class drives.

Industrial Automation
Supports drive control, monitoring, and status feedback within PLC systems.

FAQ

What does the 1769-SM1 do?
It connects the PLC to drive systems using DPI or SCANport communication.

Does it require manual baud-rate setup?
No. The module automatically detects and matches the host baud rate.
