Siemens 6ES5524-3UA12 Simatic S5 Communication Processor Module

Siemens 6ES5524-3UA12 Simatic S5 Communication Processor Module

Description

The Siemens 6ES5524-3UA12 is a dedicated communication processor module engineered for the Simatic S5 automation platform. This module is designed to offload communication tasks from the central processing unit, ensuring...

21 people are viewing this right now

Availability: Low stock: 5 left

SKU: 6ES5524-3UA12
Vendor: Siemens
Category: Communication Processor Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6ES5524-3UA12 is a dedicated communication processor module engineered for the Simatic S5 automation platform. This module is designed to offload communication tasks from the central processing unit, ensuring efficient data exchange and protocol management in industrial control systems. By handling complex network drivers and serial communication protocols independently, the CP524 helps maintain consistent cycle times in demanding applications, including power generation, chemical processing, and heavy industrial manufacturing.

Features

  • Dedicated microprocessor architecture for independent communication processing.
  • Supports standard serial protocols including RK512 and 3964R.
  • Configurable interface submodules for TTY (20 mA current loop), RS232C (V.24), and RS422/RS485.
  • Onboard memory support with RAM and EPROM sockets for parameter and data block storage.
  • High-grade noise immunity for reliable operation in high-EMI industrial environments.
  • Configurable transmission rates ranging from 300 to 19200 bps.

Technical Specifications

Model 6ES5524-3UA12
Product Family Simatic S5 / Simatic Net
Module Type Communication Processor (CP524)
Power Requirements 5 VDC (via S5 backplane), 1.5 A max
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 70 deg C
Interface Support TTY, RS232C, RS422/RS485 (via submodules)
Baud Rate 300 to 19200 bps

Installation Guidelines

  • Ensure the PLC power supply is disconnected before inserting or removing the CP524 module from the S5 rack.
  • Verify that the module is correctly seated in the designated rack slot to ensure proper backplane connection.
  • Use appropriate shielded cabling for serial interfaces to maintain signal integrity and minimize electromagnetic interference.
  • Ensure adequate ventilation within the control cabinet to maintain ambient temperatures within the specified 0 to 60 deg C range.
  • Handle with standard ESD precautions to prevent damage to sensitive internal circuitry.

FAQ

What protocols does the 6ES5524-3UA12 support?

The module supports standard Siemens serial protocols, specifically RK512 and 3964R, for communication between PLCs, operator panels, and field devices.

Does this module require external power?

No, the module draws its operating power directly from the Simatic S5 backplane (5 VDC, 1.5 A maximum).

Can I change the communication interface type?

Yes, the CP524 supports various physical interfaces including TTY, RS232C, and RS422/RS485 through the use of plug-in interface submodules.
