DC Input Module Yokogawa F3XD64-3F

DC Input Module Yokogawa F3XD64-3F

Configured for high-density digital signal acquisition in FA-M3 programmable logic controller (PLC) network platforms, the Yokogawa F3XD64-3F (F3XD64-3F DC Input Module) provides direct physical/electrical execution. This 64-channel component serves as...

18 people are viewing this right now

Availability: In stock

SKU: F3XD64-3F
Vendor: Yokogawa
Category: DC Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for high-density digital signal acquisition in FA-M3 programmable logic controller (PLC) network platforms, the Yokogawa F3XD64-3F (F3XD64-3F DC Input Module) provides direct physical/electrical execution. This 64-channel component serves as the primary F3XD64-3F interface utilized to execute sensor and switch signal processing across industrial automation platforms.

Hardware Specifications

Parameter Specification
Model F3XD64-3F
Brand Yokogawa
Origin Japan
Weight 0.31 kg
Dimensions Standard FA-M3 module form factor
Operating Temp Standard industrial ambient
Power Consumption 75 mA (5 V DC)
Input Channels 64 channels
Rated Input 24 V DC
Response Time Selectable (0 to 16 ms)

PLC Control and Photocoupler Isolation

The F3XD64-3F utilizes photocoupler isolation to ensure complete electrical separation between the field device signals and the PLC backplane bus. This architecture is critical for protecting the controller from noise and transients often encountered in large-scale machine control environments. The module supports selectable response times, allowing engineers to filter contact bounce or optimize signal throughput for specific high-speed applications. With a 100% simultaneous input rating, the module remains stable even when all 64 channels are active, maintaining reliable state transition detection for field sensors.

Frequently Asked Questions

Q: Can the response time be configured individually for each channel?

A: The response time settings for the F3XD64-3F are typically applied per module. Ensure all connected field devices on the module share similar operational characteristics to maximize the effectiveness of the selected filter setting.

Q: Is external power required for the digital input circuits?

A: Yes, the inputs are rated for a nominal 24 V DC signal. Ensure the external power supply for the field sensors is stable and within the 20.4 to 26.4 V DC operating range to prevent intermittent signal status.

Field Installation Guidelines

  • Connection: The module uses a 40-pin connector for all 64 channels. Use factory-specified pre-wired cables to ensure the correct mapping of signals and to maintain the integrity of the high-density connection.
  • Shielding: To minimize electromagnetic interference (EMI), route input signal cables in dedicated conduits or trays, keeping them physically separated from AC power lines and high-current motor drive cables.
  • Grounding: Verify that the FA-M3 base unit is connected to a low-impedance earth ground. This provides a stable reference for the input circuits and ensures the effectiveness of the internal photocoupler protection.
  • Inspection: Periodically check the 40-pin connector for any signs of loose pins or oxidation. Ensure the locking tabs are engaged to prevent disconnection due to vibration.
