Digital Input Module YOKOGAWA NFDV151-P10/D5A00

Digital Input Module YOKOGAWA NFDV151-P10/D5A00

Configured for high-density signal acquisition in N-IO (Network I/O) systems, the YOKOGAWA NFDV151-P10/D5A00 (NFDV151 Digital Input Module) provides direct physical/electrical execution. This component facilitates the sensing of field-side digital status...

20 people are viewing this right now

Availability: In stock

SKU: NFDV151-P10/D5A00
Vendor: Yokogawa
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for high-density signal acquisition in N-IO (Network I/O) systems, the YOKOGAWA NFDV151-P10/D5A00 (NFDV151 Digital Input Module) provides direct physical/electrical execution. This component facilitates the sensing of field-side digital status inputs, converting discrete voltage states into process data for integration within the distributed control system architecture.

Hardware Specifications

Parameter Specification
Model NFDV151-P10/D5A00
Brand YOKOGAWA
Origin JAPAN
Weight 0.4 kg
Dimensions 2.2 cm x 12.4 cm x 12.6 cm
Operating Temp -20 to 70 deg C
Power Consumption 2.0 W (Typical)
Signal Type Digital Input
Isolation Channel-to-channel

Channel-to-Channel Isolation and Loop Protocol

The NFDV151-P10/D5A00 module employs channel-to-channel isolation to prevent propagation of electrical faults across the input array. Designed for N-IO platform compatibility, the module maintains loop integrity by suppressing electromagnetic noise interference typical of industrial field-side wiring. Each channel utilizes opto-isolation to maintain clear signal thresholds between the 24 VDC field input and the internal backplane communication bus, ensuring consistent state detection regardless of external potential differences.

Frequently Asked Questions

Q: Is this module compatible with existing Centum VP base plates or does it require a dedicated N-IO node?

A: The NFDV151 is specifically engineered for use with N-IO nodes and field enclosures; it is not natively compatible with legacy FIO base plates.

Q: Does the module support hot-swapping during active process control?

A: Yes, this hardware is designed for hot-swap operations within the N-IO node provided that the specific system configuration supports online maintenance modes.

Field Installation Guidelines

  • Verify that the N-IO node is powered and the module slot is clear of debris before insertion.
  • Align the module along the guide rails and press firmly until the locking mechanism engages to ensure a secure backplane connection.
  • Connect field signal wiring to the designated terminal block, ensuring proper torque according to local standards to prevent intermittent contact.
  • Use shielded cabling for all digital input loops and ground the shield at the terminal cabinet to maintain noise immunity.
  • Check the status LEDs on the module faceplate post-installation to confirm successful communication with the node controller.
