Discrete Output Module Schneider Electric BMXDDO1602 Modicon X80

Discrete Output Module Schneider Electric BMXDDO1602 Modicon X80

Product Overview

The Schneider Electric BMXDDO1602 is a 16-channel digital output module for the Modicon X80 platform. Designed for M340 and M580 PLC systems, it provides 24V DC positive logic...

23 people are viewing this right now

Availability: Low stock: 94 left

SKU: BMXDDO1602
Vendor: Schneider
Category: Discrete Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The Schneider Electric BMXDDO1602 is a 16-channel digital output module for the Modicon X80 platform. Designed for M340 and M580 PLC systems, it provides 24V DC positive logic outputs for controlling relays, indicators, and industrial actuators. We supply this unit as 100% brand new and original.

Technical Specifications

Specification Details
Output Channels 16
Output Logic Positive (Source)
Operating Voltage 24V DC
Current per Channel 0.5 A
Platform Compatibility Modicon X80 (M340 / M580)
Isolation 1500 Vrms between channels and bus
Weight 0.12 kg
Dimensions 5.6 × 11.0 × 12.0 cm

Engineering Advantages

High I/O Density
Provides 16 output channels in a compact single-slot design.

Built-In Protection
Includes short-circuit and overvoltage protection for reliable operation.

Easy Diagnostics
LED indicators allow quick monitoring of output status.

Simple Wiring Integration
Compatible with Schneider terminal blocks and Telefast wiring systems.

FAQs

What does positive logic mean?
The module sources current to the connected load when the output is activated.

Can it drive motors directly?
No, high-power loads require an external relay or contactor.

Is the terminal block included?
The terminal block is usually sold separately.

Is it compatible with M580 Ethernet backplanes?
Yes, it supports both X-bus and M580 Ethernet backplane systems.
