Emerson 960177-02 Positioning Drive Module

Emerson 960177-02 Positioning Drive Module

Description

The Emerson 960177-02 is a precision-engineered Positioning Drive Module designed for advanced motion control and automated actuation within high-demand industrial sectors. This module provides the critical interface required for controlling...

17 people are viewing this right now

Availability: Low stock: 10 left

SKU: 960177-02
Vendor: Emerson
Category: Positioning Drive Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Emerson 960177-02 is a precision-engineered Positioning Drive Module designed for advanced motion control and automated actuation within high-demand industrial sectors. This module provides the critical interface required for controlling servo drives and high-speed positioning systems in applications such as power plant turbine regulation, automated material handling, and precision CNC machining. By delivering high-accuracy feedback loops and rapid response times, the 960177-02 ensures exact mechanical placement and velocity control, optimizing throughput and reducing mechanical wear.

Features

  • High-integrity signal processing for stability in electrically noisy environments.
  • Dedicated inputs for encoder feedback and high-speed digital I/O.
  • Advanced PID algorithms for managing acceleration and deceleration ramps.
  • Real-time diagnostic reporting for monitoring drive status and position deviations.
  • Ruggedized construction with passive thermal management for continuous duty cycles.

Applications

This module is suitable for use in complex manufacturing environments, power generation facilities, and automated systems requiring precise mechanical positioning, including turbine regulation, material handling, and CNC machining.

Technical Specifications

Model 960177-02
Brand Emerson
Product Type Positioning Drive Module
Input Voltage 24 VDC (Logic Power)
Signal Interface High-speed Encoder / Pulse-Direction
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 85 deg C
Relative Humidity 5 to 95 percent Non-Condensing
Protection Rating IP 20
Shock Resistance 15g for 11 msec
Vibration Resistance 1g at 5 to 150 Hz
Cooling Natural Convection
Communication Backplane Bus Interface

Installation Guidelines

  • Ensure the control rack power is disconnected before installing or removing the module.
  • Handle the module using ESD-safe practices to prevent damage to sensitive electronic components.
  • Ensure the module is fully seated in the backplane slot to maintain reliable bus communication.
  • Maintain adequate clearance around the module to allow for natural convection and passive heat dissipation.
  • Route signal cables away from high-EMI sources such as power lines or heavy motor contactors.
  • Verify that the 24 VDC logic power supply is stable and within specified operating limits.

FAQ

Is this module compatible with existing Emerson control racks?

Yes, the 960177-02 is designed for seamless integration into standard Emerson control racks supporting the backplane bus interface.

What is the primary function of the 960177-02?

It acts as a Positioning Drive Module, providing high-accuracy control for servo drives and positioning systems through encoder feedback and pulse-direction signaling.
