Emerson Control Techniques FX-340 Servo Drive

Emerson Control Techniques FX-340 Servo Drive

Description

The Emerson FX-340 is a high-performance positioning servo drive engineered for precise motion control in demanding industrial environments. As a core component of the Control Techniques motion family, this drive...

20 people are viewing this right now

Availability: Low stock: 2 left

SKU: FX-340
Vendor: Emerson
Category: Servo Drive
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Emerson FX-340 is a high-performance positioning servo drive engineered for precise motion control in demanding industrial environments. As a core component of the Control Techniques motion family, this drive integrates advanced positioning logic with high-torque motor control to handle complex automation sequences. It is widely utilized in high-speed packaging lines, CNC machining, and automated assembly systems within the automotive and electronics manufacturing sectors. By providing rapid response times and high-resolution feedback loops, the FX-340 ensures optimal machine throughput and maintains strict operational tolerances.

Features

  • High-speed digital signal processor (DSP) for complex motion profiles including indexing, camming, and electronic gearing.
  • Supports multiple feedback interfaces including incremental encoders, resolvers, and SinCos sensors.
  • Integrated protection circuits for overvoltage, overcurrent, and phase loss.
  • Standard RS-232/RS-485 communication with support for optional fieldbus modules.
  • Robust design for reduced mechanical wear and smooth acceleration/deceleration profiles.

Applications

The FX-340 is designed for applications requiring high-precision motion, such as:

  • High-speed packaging and labeling machinery.
  • CNC machine tool axes control.
  • Automated assembly and pick-and-place systems.
  • Precision material handling and web tensioning.

Technical Specifications

Model FX-340 (960133-01)
Brand Emerson / Control Techniques
Module Type Positioning Servo Drive
Input Voltage 230 VAC / 460 VAC (Model Dependent)
Output Current 4.0 A Continuous / 8.0 A Peak
Feedback Supported Incremental Encoder, Resolver, SinCos
Operating Temperature 0 to 50 deg C
Storage Temperature -20 to 70 deg C
Relative Humidity 5 to 95% non-condensing
Protection Class IP20
Communication RS-232 / RS-485

Installation Guidelines

  • Ensure the drive is mounted in a vertical position within an IP54 or better enclosure to protect against dust and moisture.
  • Maintain adequate clearance around the unit to allow for natural convection cooling; do not block airflow vents.
  • Use shielded cables for all feedback and communication signals to minimize EMI interference.
  • Ensure the drive chassis is connected to a low-impedance protective earth (PE) ground.
  • Always disconnect all power sources and wait for internal capacitors to discharge before performing wiring or maintenance.
  • Verify that input voltage matches the specific drive configuration before applying power.

FAQ

What type of feedback devices are compatible with the FX-340?

The drive supports incremental encoders, resolvers, and SinCos feedback devices, allowing for flexible integration with various motor types.

Can the FX-340 be used in a networked environment?

Yes, the unit features standard RS-232/RS-485 ports and supports optional fieldbus modules for integration into larger PLC-based control architectures.
