Emerson DeltaV KJ4006X1-BP1 40-Pin Mass Terminal Block

Emerson DeltaV KJ4006X1-BP1 40-Pin Mass Terminal Block

Description

The Emerson DeltaV KJ4006X1-BP1 is a 40-pin Mass Terminal Block designed for the DeltaV S-Series digital automation platform. It serves as the essential physical interface between field instrumentation wiring and...

22 people are viewing this right now

Availability: Low stock: 9 left

SKU: KJ4006X1-BP1
Vendor: Emerson
Category: Terminal Block
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Emerson DeltaV KJ4006X1-BP1 is a 40-pin Mass Terminal Block designed for the DeltaV S-Series digital automation platform. It serves as the essential physical interface between field instrumentation wiring and the corresponding I/O cards. By providing a high-density termination point, this block simplifies field wiring management, reduces installation time, and ensures reliable signal integrity in critical process control environments.

Features

  • 40-pin high-density interface for efficient field wiring.
  • Mechanical rotary keying system to prevent incorrect I/O card insertion.
  • Designed for use in Class I Division 2 and Zone 2 hazardous locations.
  • Compliant with ISA-S71.04 Class G3 standards for protection against corrosive contaminants.
  • Maintenance-free, calibration-less design for long-term operational reliability.

Applications

This terminal block is utilized in DeltaV S-Series systems across various industrial sectors, including oil and gas, chemical processing, and power generation, where secure and organized field-to-controller signal distribution is required.

Technical Specifications

Brand Emerson
Model KJ4006X1-BP1
Type 40-Pin Mass Terminal Block
System Series DeltaV S-Series
Field Power Rating 30 VDC at 3.2 A
Operating Temperature -40 to +70 deg C
Relative Humidity 5 to 95 percent (Non-Condensing)
Shock Resistance 10 g (11 ms half-sinewave)
Vibration Resistance 1 mm P-P (2-13.2 Hz); 0.7 g (13.2-150 Hz)
Contaminant Rating ISA-S71.04-1985 Class G3

Installation Guidelines

  • Ensure the rotary keying system is correctly configured to match the specific I/O card type before installation.
  • Always power down the system or ensure no I/O card is present before installing or removing the terminal block.
  • Ensure all field wiring is disconnected prior to removing the block from the carrier.
  • Maintain proper grounding practices as per DeltaV S-Series installation manuals to ensure EMI protection.
  • Handle with care to avoid damage to the 40-pin connector pins during alignment and seating.

Compliance and Certifications

The KJ4006X1-BP1 holds multiple hazardous area certifications, including FM19ATEX0173U, IECEx FMG 19.0019U, FM21UKEX0017U, FM17CA0145U, and FM17US0286U. It is rated for Class I Division 2, Groups A, B, C, D and Zone 2 AEx/Ex ec IIC Gc environments.

FAQ

Is this terminal block user-serviceable?

No, the KJ4006X1-BP1 is a maintenance-free, calibration-less component with no user-serviceable internal parts.

Can this block be used in corrosive environments?

Yes, the unit is compliant with ISA-S71.04 Class G3 standards, making it suitable for environments with airborne corrosive contaminants.
