Foxboro P0916AE I/A Series Termination Assembly

Foxboro P0916AE I/A Series Termination Assembly

Description

The Foxboro P0916AE is a high-reliability Termination Assembly (TA) designed for the I/A Series 200 Series distributed control system (DCS) architecture. This terminal card acts as the essential physical interface...

23 people are viewing this right now

Availability: Low stock: 9 left

SKU: P0916AE
Vendor: Foxboro
Category: Termination Assembly
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Foxboro P0916AE is a high-reliability Termination Assembly (TA) designed for the I/A Series 200 Series distributed control system (DCS) architecture. This terminal card acts as the essential physical interface between field-side instrumentation wiring and the Fieldbus Modules (FBMs). By providing a robust, organized connection point, the P0916AE ensures secure signal routing, simplifies maintenance procedures, and protects sensitive control electronics from field-side wiring faults. It is engineered for deployment in demanding industrial environments, including power generation, petrochemical processing, and mining operations.

Features

  • System Integration: Designed specifically for seamless mounting within the Foxboro I/A Series 200 hardware ecosystem.
  • Signal Protection: Integrated circuit protection helps prevent field-side electrical faults from propagating to the FBMs.
  • Troubleshooting Access: Includes dedicated test points allowing for real-time circuit diagnostics without the need to disconnect field wiring.
  • Redundancy Support: Supports redundant cabling configurations to maintain signal continuity in critical control loops.
  • EMI/RFI Shielding: Facilitates effective grounding strategies to protect digital logic from electromagnetic and radio frequency interference.

Applications

The P0916AE is widely utilized in industrial automation systems where high-density I/O connectivity is required. Typical applications include:

  • Petrochemical and refinery process control.
  • Power generation and distribution monitoring.
  • Mining and mineral processing automation.
  • Continuous process manufacturing where high availability is critical.

Technical Specifications

Model P0916AE
Brand Foxboro (Schneider Electric)
Module Type Termination Assembly (TA)
Series I/A Series 200
Connection Type Screw-terminal / Compression-style
Max Input Voltage 30 VDC
Max Current Rating 2 A per point
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 70 deg C
Relative Humidity 5 to 95 percent (non-condensing)

Installation Guidelines

  • ESD Precautions: Always use a grounded wrist strap when handling the module to prevent electrostatic discharge damage to internal components.
  • Power Status: Ensure all power to the I/O rack is disconnected before installing or removing the terminal card from the baseplate.
  • Wiring: Ensure all field wires are properly secured in the terminals. Verify that wire gauges are compatible with the terminal block specifications to prevent loose connections.
  • Grounding: Follow standard Foxboro grounding practices for the I/A Series to ensure effective shielding against EMI/RFI.
  • Environment: Ensure the installation location provides adequate ventilation to maintain operating temperatures within the specified 0 to 60 deg C range.

FAQ

What is the primary function of the P0916AE?

The P0916AE is a Termination Assembly that provides the physical interface between field wiring and Foxboro I/A Series 200 Fieldbus Modules, facilitating signal routing and circuit protection.

Can this module be used in redundant systems?

Yes, the P0916AE supports redundant cabling configurations, which is essential for maintaining signal continuity in critical control loops.

Is this module compatible with all I/A Series systems?

The P0916AE is specifically designed for the I/A Series 200 hardware ecosystem. Always verify your specific FBM compatibility before installation.
