General Electric IC693CHS391E 10-Slot CPU Baseplate

General Electric IC693CHS391E 10-Slot CPU Baseplate

The General Electric IC693CHS391E is a 10-slot modular baseplate designed for the GE Fanuc Series 90-30 PLC system. This expansion baseplate provides the necessary physical mounting and electrical backplane connectivity...

20 people are viewing this right now

Availability: Low stock: 4 left

SKU: IC693CHS391E
Vendor: General Electric
Category: PLC Baseplate
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The General Electric IC693CHS391E is a 10-slot modular baseplate designed for the GE Fanuc Series 90-30 PLC system. This expansion baseplate provides the necessary physical mounting and electrical backplane connectivity for a CPU module and various I/O or specialty modules, facilitating scalable automation configurations.

Features

  • Ten (10) total slots for system configuration.
  • Dedicated slot for one (1) CPU or specialty module (Slot 1).
  • Nine (9) dedicated slots for I/O or option modules (Slots 2-10).
  • Integrated power supply module slot.
  • 25-pin female connector for system communication.
  • Supports PCI card connectivity.

Technical Specifications

Model IC693CHS391E
Series Series 90-30
Total Slots 10
CPU/Specialty Slots 1 (Slot 1)
I/O Option Slots 9 (Slots 2-10)
Voltage 5V DC
Current Consumption 420 mA
Connector Type 25-Pin Female

Installation Guidelines

  • Ensure the power supply is disconnected before installing or removing any modules from the baseplate.
  • Mount the baseplate securely on a flat, vibration-resistant surface within the control cabinet.
  • Maintain adequate clearance around the baseplate to allow for proper airflow and cooling.
  • Use shielded cables for I/O connections to minimize electromagnetic interference (EMI).
  • Ensure proper grounding of the baseplate to the cabinet ground bus to prevent electrical noise and potential damage to sensitive components.
  • Handle modules using ESD-safe practices to prevent damage to internal circuitry.

FAQ

What is the primary function of the IC693CHS391E?

The IC693CHS391E serves as the primary mounting and communication backplane for the GE Series 90-30 PLC, allowing the CPU to interface with up to nine additional I/O or specialty modules.

Can this baseplate be used for expansion?

Yes, this unit is designed as a modular baseplate that supports the expansion of the Series 90-30 system architecture, provided the power supply capacity is sufficient for the total module load.
