The IC670ALG240 is a high-density analog input module for the GE Fanuc Field Control architecture. It mounts directly on a Bus Interface Unit (BIU) or expansion base and provides 16...
Availability: Low stock: 10 left
Reliable Worldwide Delivery
30-Day Money-Back Guarantee
Need more details? Read our fullShipping PolicyandRefund Policy.
The IC670ALG240 is a high-density analog input module for the GE Fanuc Field Control architecture. It mounts directly on a Bus Interface Unit (BIU) or expansion base and provides 16 independent, isolated current input channels for precise process measurement.
Each channel features a dedicated 16-bit ADC, converting low-level field signals into high-resolution digital data with minimal noise, enabling reliable data acquisition in complex industrial control loops.
| Parameter | Specification |
|---|---|
| Model Number | IC670ALG240 |
| I/O Series | Field Control |
| Channel Count | 16 isolated current inputs |
| Signal Compatibility | 4–20 mA, 0–20 mA, 0–25 mA |
| ADC Resolution | 16-bit |
| Current Consumption | 251 mA maximum from BIU backplane |
| External Power | 20–28 VDC nominal loop power |
| Thermal Stability | ±0.002%/°C typical, ±0.005%/°C maximum |
| Wiring Support | ANSI Type 2 (2-wire) and Type 3 (3-wire) transmitters |
| Input Impedance | Precision burden resistor for loop stability |
| Operating Temperature | 0°C to 55°C (32°F to 131°F) |
| Weight | 0.26 kg |
The IC670ALG240 includes robust internal self-checks:
Monitors A/D conversion health and calibration validity
Detects underrange/overrange conditions per channel
Alerts for individual channel high/low alarms
Ensures early detection of sensor failure or line breaks
These features help maintain system uptime and ensure high-quality, reliable data for control and safety systems.
The IC670ALG240 is widely used for:
Process monitoring of flow meters, pressure transmitters, and liquid level sensors
Bridging signals from VFDs or single-loop controllers to central control logic
Integration of analytical instrumentation such as turbidity or chemical sensors
High-precision industrial monitoring loops requiring current-based inputs
Does this module support voltage inputs?
No. The IC670ALG240 is optimized for current inputs. Voltage measurement requires a separate voltage input module from the IC670 series.
Is calibration required upon installation?
The module is factory-calibrated. Internal diagnostics continuously monitor calibration status and will alert the operator if data is missing or out of range, ensuring consistent, reliable measurement.
