GE Fanuc IC694MDL660 Discrete Input Module

GE Fanuc IC694MDL660 Discrete Input Module

Product Description

The IC694MDL660 is a high-density 32-point discrete input module designed for the GE Fanuc PACSystems RX3i platform. It features four isolated groups of eight input channels, providing robust signal acquisition, flexible configuration, and excellent noise...

15 people are viewing this right now

Availability: Low stock: 99 left

SKU: IC694MDL660
Vendor: GE Fanuc
Category: Discrete Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The IC694MDL660 is a high-density 32-point discrete input module designed for the GE Fanuc PACSystems RX3i platform. It features four isolated groups of eight input channels, providing robust signal acquisition, flexible configuration, and excellent noise immunity in industrial control applications. Its compact, high-density design optimizes space in the rack while reliably monitoring 24 VDC field devices.

Technical Specifications

Parameter Specification
Model Number IC694MDL660
Manufacturer GE Fanuc / Emerson
Series Compatibility PACSystems RX3i
Input Channels 32 (4 groups of 8)
Nominal Voltage 24 VDC
Input Voltage Range 0 – 30 VDC
On-State Voltage 11.5 – 30 VDC
Off-State Voltage 0 – 5 VDC
Weight 0.23 kg

Applications

  • High-density discrete input monitoring in industrial automation systems

  • Enhanced noise immunity for mechanical switches and sensors

  • Flexible multi-voltage configurations via isolated channel groups

  • Rack space optimization in PACSystems RX3i deployments

Operational Features

  • Configurable Input Filtering: Select filter times from 0.5 ms to 100 ms to suppress contact bounce, transients, and electrical noise.

  • Electrical Isolation: Four groups of eight inputs are electrically isolated for multi-voltage flexibility and improved safety.

  • Channel Status Monitoring: Each input channel includes a dedicated front-panel LED for real-time logic state indication.

Frequently Asked Questions

What are the filter settings used for?
Filter settings suppress unwanted noise, contact bounce, and transient signals, ensuring only valid input state changes are processed by the controller.

Are the input groups electrically isolated?
Yes, the four groups of eight channels are fully isolated from each other, allowing separate power sources or voltage levels without interference.

How do I confirm the status of a specific input channel?
Each channel has a dedicated LED: illuminated = Logic 1 (input active), off = Logic 0 (inactive).
