General Electric IC695PBM300 PACSystems RX3i PROFIBUS Master Module

General Electric IC695PBM300 PACSystems RX3i PROFIBUS Master Module

The General Electric IC695PBM300 is a high-performance PROFIBUS Master module designed for the PACSystems RX3i control platform. This module enables the RX3i CPU to function as a master on a...

24 people are viewing this right now

Availability: Low stock: 1 left

SKU: IC695PBM300
Vendor: General Electric
Category: Communication Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The General Electric IC695PBM300 is a high-performance PROFIBUS Master module designed for the PACSystems RX3i control platform. This module enables the RX3i CPU to function as a master on a PROFIBUS-DP network, facilitating seamless communication with up to 125 slave devices. It is engineered to support both standard PROFIBUS data rates and DP-V1 functionality, including read, write, and alarm messaging, making it a robust solution for distributed control and I/O management.

Features

  • Supports PROFIBUS-DP V1 master functionality.
  • Capable of managing up to 125 DP slave devices.
  • Provides 244 bytes of input data and 244 bytes of output data per slave.
  • Integrated status LEDs for both module and network health monitoring.
  • Supports all standard PROFIBUS data transmission rates.

Technical Specifications

Model Number IC695PBM300
Product Line PACSystems RX3i
Communication Protocol PROFIBUS-DP
Power Consumption 440 mA at 3.3 VDC
Slot Requirement Single Slot
Max Supported Slaves 125
Data Capacity 244 Bytes Input / 244 Bytes Output
Interface RS-232 (for configuration/diagnostics)

Installation Guidelines

  • Ensure the RX3i CPU is running firmware version 2.9 or later prior to installation.
  • The module must be installed in an RX3i Universal Backplane.
  • Always power down the backplane before inserting or removing the module to prevent electrical damage.
  • Ensure proper grounding of the PROFIBUS network cable shield to minimize EMI interference.
  • Firmware upgrades for this module are performed indirectly via the host controller CPU using the WinLoader software utility.

Applications

The IC695PBM300 is primarily utilized in industrial automation environments requiring integration between the PACSystems RX3i controller and third-party PROFIBUS-compliant field devices, such as remote I/O blocks, variable frequency drives, and intelligent sensors.

FAQs

What is the primary function of the IC695PBM300?

It acts as a PROFIBUS-DP master, allowing the RX3i system to communicate with and control up to 125 slave devices on a PROFIBUS network.

What are the power requirements for this module?

The module draws 440 mA from the 3.3 VDC power supply provided by the RX3i backplane.

Can this module be used with older Series 90-30 hardware?

While it can be integrated into systems with legacy components, users should consult the GFK-2301 manual to review specific differences in CommReq status words and data field structures.
