General Electric IC697MDL240 Series 90-70 Discrete Input Module

General Electric IC697MDL240 Series 90-70 Discrete Input Module

Description

The General Electric IC697MDL240 is a high-performance discrete input module engineered for the Series 90-70 Programmable Logic Controller (PLC) platform. This module is designed to provide reliable signal acquisition in...

28 people are viewing this right now

Availability: Low stock: 9 left

SKU: DS6815PCDP1B1A
Vendor: General Electric
Category: Discrete Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The General Electric IC697MDL240 is a high-performance discrete input module engineered for the Series 90-70 Programmable Logic Controller (PLC) platform. This module is designed to provide reliable signal acquisition in demanding industrial environments, featuring 16 isolated input channels that ensure signal integrity and protection against ground loops. It is specifically built to interface with 120V AC field devices, offering robust monitoring capabilities for automation control systems.

Features

  • 16 isolated discrete input channels for enhanced system safety and noise immunity.
  • Designed for seamless integration with the GE Series 90-70 PLC backplane.
  • Standardized 120V AC input voltage compatibility for common industrial sensors and switches.
  • Integrated input filter delay of 20 ms to effectively debounce incoming signals.
  • Compact modular design for efficient rack-space utilization.

Technical Specifications

Model Number IC697MDL240
Manufacturer General Electric
Series Series 90-70
Input Channels 16 Isolated Inputs
Rated Voltage 120V AC
Input Current 10 mA
Input Filter Delay 20 ms
Frequency 60 Hz
Current Consumption 0.25 A

Installation Guidelines

  • Ensure the PLC rack power is disconnected before installing or removing the module to prevent electrical damage.
  • Verify that the module is fully seated in the designated rack slot and that the locking mechanism is engaged.
  • Use appropriate shielded cabling for field inputs to minimize electromagnetic interference (EMI).
  • Maintain adequate clearance around the module to facilitate proper airflow and cooling within the enclosure.
  • Verify that field wiring matches the terminal assignment documentation to avoid short circuits or incorrect signal mapping.

FAQ

What is the primary function of the IC697MDL240?
This is a 16-point discrete input module used to detect the status of 120V AC field devices and communicate that state to the Series 90-70 PLC processor.

Are the inputs on this module isolated?
Yes, the module features 16 isolated inputs, which helps prevent electrical noise and ground loops from affecting the PLC control logic.

What is the input filter delay for this module?
The IC697MDL240 has a fixed input filter delay of 20 ms to assist in filtering out transient noise from field signals.
