GE Fanuc IC694MDL646 PACSystems RX3i 16-Point Discrete Input Module

GE Fanuc IC694MDL646 PACSystems RX3i 16-Point Discrete Input Module

Description

The GE Fanuc IC694MDL646 is a high-density 16-point discrete input module designed for the PACSystems RX3i control platform. This module is engineered to reliably interface 24 VDC field signals into...

27 people are viewing this right now

Availability: Low stock: 7 left

SKU: IC694MDL646
Vendor: GE FANUC
Category: Discrete Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The GE Fanuc IC694MDL646 is a high-density 16-point discrete input module designed for the PACSystems RX3i control platform. This module is engineered to reliably interface 24 VDC field signals into the control system, ensuring precise signal acquisition across diverse industrial applications, including chemical processing, power distribution, and automated manufacturing lines. The IC694MDL646 is built to withstand rigorous physical conditions, featuring high resistance to shock and vibration. By providing consistent input monitoring and high electrical isolation, the module serves as a cornerstone for maintaining system integrity and reducing unplanned maintenance outages in complex control environments.

Features

  • 16 independent discrete input points for high-density signal monitoring.
  • Compatible with the standard PACSystems RX3i backplane for seamless system integration.
  • Supports a wide input voltage range of 0 to 30 VDC.
  • High electrical isolation to protect the backplane and ensure signal integrity.
  • Robust physical construction with high shock and vibration resistance for harsh industrial environments.
  • Dual power source design utilizing both the 5 VDC backplane bus and a 24 VDC auxiliary supply.

Applications

This module is suitable for a wide range of industrial automation tasks, including:

  • Automated manufacturing and assembly lines.
  • Chemical and petrochemical processing plants.
  • Power generation and distribution control systems.
  • General-purpose digital signal acquisition for PLC-based control architectures.

Technical Specifications

Model IC694MDL646
Brand GE Fanuc
Product Series PACSystems RX3i
Module Type 16-Point Discrete Input Module
Rated Voltage 24 VDC
Input Voltage Range 0 to 30 VDC
Input Current 7 mA
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 85 deg C
Power Consumption 80 mA (5 VDC bus), 125 mA (24 VDC supply)
Shock Resistance 15G at 11 ms
Vibration Resistance 10 to 57 Hz (0.0524 mm peak), 57 to 500 Hz (1.0 g acceleration)
Humidity 5% to 95% (non-condensing)

Installation Guidelines

  • Ensure the RX3i power supply is disconnected before inserting or removing the module from the backplane.
  • Verify that the module is fully seated in the rack slot and secured with the integrated locking mechanism.
  • Use shielded cabling for field inputs to minimize electromagnetic interference (EMI) in high-noise environments.
  • Ensure proper grounding of the RX3i chassis to a common earth point to maintain electrical safety and signal integrity.
  • Maintain adequate ventilation around the module to ensure operation within the specified 0 to 60 deg C temperature range.
  • Handle the module using standard ESD (Electrostatic Discharge) precautions to prevent damage to internal circuitry.

FAQ

What is the primary function of the IC694MDL646?

The IC694MDL646 is a discrete input module that converts 24 VDC field signals into data that the PACSystems RX3i processor can utilize for control logic.

Does this module require external power?

Yes, the module requires both 5 VDC from the backplane bus and a 24 VDC auxiliary power supply for operation.

Can this module be used in high-vibration environments?

Yes, the module is designed with industrial-grade hardening, including resistance to 15G shock and vibration profiles up to 500 Hz.
