GE Fanuc IS200EACFG2A EX2100 Input/Output Terminal Board

GE Fanuc IS200EACFG2A EX2100 Input/Output Terminal Board

Description

The GE Fanuc IS200EACFG2A is an Input/Output (I/O) terminal board designed for the EX2100 Excitation Control series. This component is engineered for power generation applications, including gas, hydro, and thermal...

20 people are viewing this right now

Availability: Low stock: 8 left

SKU: IS200EACFG2A
Vendor: GE FANUC
Category: I/O Terminal Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The GE Fanuc IS200EACFG2A is an Input/Output (I/O) terminal board designed for the EX2100 Excitation Control series. This component is engineered for power generation applications, including gas, hydro, and thermal turbine systems, where it functions as a primary interface for high-voltage monitoring and control signaling. The G2 version incorporates advanced transformer integration to support accurate three-phase input voltage measurement up to 1000 VRMS, ensuring stable generator excitation and reliable signal processing.

Features

  • Integrated four-transformer architecture (T1, T2, T3, T4) for high-fidelity voltage monitoring.
  • Dedicated TB4 terminal for flux and air core coil inputs.
  • Supports Power Potential Transformer (PPT) signal sensing.
  • Optimized layout for systematic signal routing in auxiliary control cabinets.
  • Robust construction designed for high-voltage measurement environments.

Applications

This terminal board is utilized in power generation facilities for generator excitation control, voltage regulation, and monitoring of flux coil data. It is essential for maintaining generator stability and preventing unplanned downtime in industrial power plants.

Technical Specifications

Model IS200EACFG2A
Series EX2100 Excitation Control
Component Type I/O Terminal Board
Voltage Measurement Up to 1000 VRMS
Transformers 4 Phase-Voltage Transformers
Connector TB4 Flux/Air Core Input
Weight 0.68 kg

Installation Guidelines

  • Ensure the system is fully de-energized before installing or removing the board to prevent electrical shock or damage to the circuitry.
  • Follow proper ESD (Electrostatic Discharge) handling procedures when touching the board components.
  • Verify that all high-voltage measurement paths are correctly wired and labeled to maintain signal integrity.
  • Ensure the board is securely mounted within the auxiliary control cabinet and that all terminal connections are tightened to specified torque requirements.
  • Maintain proper cable routing to separate high-voltage signal lines from low-voltage control logic to minimize EMI interference.

FAQ

What is the primary function of the IS200EACFG2A board?

The IS200EACFG2A serves as an I/O terminal board for the EX2100 Excitation Control system, specifically handling three-phase voltage monitoring and flux coil signal processing for generator excitation.

Can this board handle 1000 VRMS?

Yes, the IS200EACFG2A is designed to support three-phase input voltage measurements up to 1000 VRMS.

What does the TB4 terminal on this board do?

The TB4 terminal is specifically configured to interface with flux and air core coils, allowing for the integration of flux coil data into the excitation control system.
