General Electric IS200TRLYH1BED Relay Terminal Board

General Electric IS200TRLYH1BED Relay Terminal Board

Description

The IS200TRLYH1BED is a Relay Terminal Board designed for the General Electric Mark VIe control system. This board provides reliable relay output interfacing, facilitating the distribution of power and control...

23 people are viewing this right now

Availability: Low stock: 2 left

SKU: IS200TRLYH1BED
Vendor: General Electric
Category: Relay Terminal Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The IS200TRLYH1BED is a Relay Terminal Board designed for the General Electric Mark VIe control system. This board provides reliable relay output interfacing, facilitating the distribution of power and control signals within industrial automation environments. It is engineered to support high-density relay switching, featuring multiple fused branches and a variety of relay configurations to meet specific application requirements.

Features

  • Equipped with 12 Form C relays for versatile switching operations.
  • Includes 6 fused branches for circuit protection and 1 special unfused branch.
  • Supports diverse voltage and current ratings: 24V DC at 3A, 125V DC at 0.6A, and 120/240V AC at 3A.
  • Designed for seamless integration with the Mark VIe control architecture.

Technical Specifications

Product Model IS200TRLYH1BED
Spare Model IS200TRLYH1B
Manufacturer General Electric
Relay Type 12 Form C Relays
Power Distribution 6 Fused Branches, 1 Unfused
Tariff Code 8537101190

Installation Guidelines

  • Ensure the control system is powered down before installing or removing the terminal board to prevent electrical damage or injury.
  • Verify that all wiring connections are secure and properly terminated according to the system wiring diagrams.
  • Maintain proper grounding practices to minimize electromagnetic interference (EMI) and ensure signal integrity.
  • Handle the board using ESD-safe procedures to protect sensitive electronic components from electrostatic discharge.
  • Ensure adequate ventilation in the cabinet to prevent thermal buildup during continuous operation.

FAQ

What is the primary function of the IS200TRLYH1BED?

This board acts as a relay terminal interface for the Mark VIe system, allowing the controller to switch external field devices using its onboard Form C relays.

Can this board be used as a replacement for the IS200TRLYH1B?

Yes, the IS200TRLYH1BED is often utilized as a functional replacement or upgrade for the IS200TRLYH1B model. Please verify your specific system revision requirements before installation.
