General Electric IC200CHS002D VersaMax Box-Style I/O Carrier

General Electric IC200CHS002D VersaMax Box-Style I/O Carrier

Description

The General Electric IC200CHS002D is a box-style I/O carrier designed for the VersaMax PLC series. This carrier provides the necessary physical interface and electrical connection points for mounting and wiring...

23 people are viewing this right now

Availability: Low stock: 7 left

SKU: IC200CHS002D
Vendor: General Electric
Category: I/O Carrier
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The General Electric IC200CHS002D is a box-style I/O carrier designed for the VersaMax PLC series. This carrier provides the necessary physical interface and electrical connection points for mounting and wiring VersaMax I/O modules, facilitating reliable signal distribution and power management within an industrial automation system.

Features

  • Integrated terminal design for efficient field wiring.
  • Supports 36 box-style terminals for high-density I/O configurations.
  • Designed for standard DIN rail mounting in horizontal orientations.
  • Rated for operation up to 264 VAC with transient voltage protection up to 300 VAC.
  • Supports a per-point current rating of 2 Amps and a total segment current capacity of 8 Amps.

Technical Specifications

Model IC200CHS002D
Series VersaMax
Terminal Count 36
Voltage Rating 0-264 VAC
Transient Voltage 300 VAC
Per Point Current 2 Amps
Segment Current Rating 8 Amps
Mounting DIN Rail (Horizontal)
Compatible Wire Size AWG 14-22 (Single), AWG 18 (Dual)

Installation Guidelines

  • Ensure the DIN rail is securely mounted and grounded before installing the carrier.
  • Maintain a minimum clearance of 2 inches (5.1 cm) at the top and bottom, and 1 inch (2.54 cm) on the sides to ensure adequate ventilation and access.
  • Verify that power is disconnected from the system before inserting or removing any I/O modules from the carrier.
  • Use appropriate wire gauges (AWG 14-22) and ensure terminals are tightened to specified torque to prevent loose connections and signal interference.
  • Route signal cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.

FAQ

What is the primary function of the IC200CHS002D?

The IC200CHS002D acts as a base carrier for VersaMax I/O modules, providing the mechanical mounting surface and the electrical terminal blocks required to connect field devices to the PLC system.

Can this carrier be mounted vertically?

The IC200CHS002D is designed for horizontal mounting. Please refer to the VersaMax system documentation for specific derating requirements if alternative orientations are necessary.

What is the maximum wire size supported by the terminals?

The terminals support single wire connections from AWG 14 to AWG 22, or dual wire connections using AWG 18 wire.
