Generator Load Sensor Woodward 8290-048

Generator Load Sensor Woodward 8290-048

Product Description

The 8290-048 is a high-accuracy load sensing module developed by Woodward, Inc. for kW measurement and load-sharing applications in synchronous generator systems.

The module converts electrical measurements from Potential Transformers...

28 people are viewing this right now

Availability: Low stock: 99 left

SKU: 8290-048
Vendor: Woodward
Category: Generator Load Sensor
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 8290-048 is a high-accuracy load sensing module developed by Woodward, Inc. for kW measurement and load-sharing applications in synchronous generator systems.

The module converts electrical measurements from Potential Transformers (PT) and Current Transformers (CT) into a proportional DC output signal used by speed governors to maintain balanced load distribution across multiple generators or during utility grid connection. This helps prevent engine overloading and ensures stable power quality in parallel operation systems.

Its rugged analog design provides reliable performance in harsh industrial environments such as marine power systems, mining sites, and distributed generation plants.

Technical Specifications

Parameter Specification
Model 8290-048
Function Real-power (kW) load sensing
Input Voltage Range 95–130 VAC / 190–260 VAC
Frequency Compatibility 50 Hz / 60 Hz
Power Consumption 5 VA
Input Type PT and CT measurement inputs
Output Signal Linear DC proportional to kW load
Compatibility 2301, EPG, and EG load-sharing systems
Mounting Internal chassis mounting with screw terminals
Weight 1.65kg
Operating Temperature Engine-room industrial temperature range

Application

  • Generator paralleling and load sharing systems

  • Marine vessel power management

  • Mining and remote site power plants

  • Co-generation and distributed generation facilities

FAQ

Does it measure reactive power (kVAR)?
No. It only measures real power (kW). Reactive power requires AVR or dedicated kVAR control systems.

Can it be used on 480V systems?
Yes, but only through a Potential Transformer to step voltage down to the module input range.

Is it suitable for diesel and gas engines?
Yes. The module measures electrical output from the alternator, making it fuel-type independent.
