Honeywell 51155506-140 Experion LX Relay Cable Assembly

Honeywell 51155506-140 Experion LX Relay Cable Assembly

Description

The Honeywell 51155506-140 is a high-quality relay cable assembly designed for use within the Experion LX distributed control system architecture. This cable assembly is specifically engineered to facilitate reliable signal...

26 people are viewing this right now

Availability: Low stock: 8 left

SKU: 51155506-140
Vendor: Honeywell
Category: Relay Cable Assembly
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Honeywell 51155506-140 is a high-quality relay cable assembly designed for use within the Experion LX distributed control system architecture. This cable assembly is specifically engineered to facilitate reliable signal transmission for Digital Output (DO) source applications. With a total length of 40 meters, it provides the necessary reach for complex industrial cabinet configurations, ensuring robust connectivity between the control hardware and field termination assemblies.

Features

  • Designed for Experion LX system compatibility
  • Configured for Digital Output (DO) source signal routing
  • Total cable length: 40.0 meters
  • Robust construction suitable for industrial environments
  • High dielectric strength for electrical safety

Technical Specifications

Product Model 51155506-140
Cable Type Relay Cable Assembly
Application DO (Source)
Length 40.0 Meters
Dielectric Strength 1000V AC for 1 minute
Conductor Resistance ≤25 Ohm/km (typical)
Operating Temperature -40 degC to +85 degC
Storage Temperature -50 degC to +90 degC
Humidity Resistance 90% RH (non-condensing)
Tariff Code 8537101190

Installation Guidelines

  • Ensure all power is disconnected from the I/O modules and field devices before connecting or disconnecting the cable assembly.
  • Route cables through dedicated industrial cable trays to minimize electromagnetic interference (EMI) from high-voltage power lines.
  • Avoid sharp bends or excessive tension during installation to maintain the integrity of the internal conductors.
  • Verify that the connector pins are clean and free of debris before mating with the corresponding module or terminal block.
  • Secure the cable using appropriate strain relief methods to prevent mechanical stress on the connection points.

FAQ

What is the primary function of the 51155506-140 cable?

This cable assembly is used to interface Digital Output (DO) source signals within the Honeywell Experion LX system, providing a reliable physical link between control system modules and field termination points.

Can this cable be used in extreme temperatures?

Yes, the cable is rated for an operating temperature range of -40 degC to +85 degC, making it suitable for most standard industrial control room and plant floor environments.
