Honeywell 51304485-150 MC-PDIX02 Digital Input Module

Honeywell 51304485-150 MC-PDIX02 Digital Input Module

Description

The Honeywell MC-PDIX02 (51304485-150) is a high-density Digital Input Processor module designed for integration within the Fault Tolerant Ethernet (FTE) and FSC (Fail Safe Controller) systems. This module provides 32...

28 people are viewing this right now

Availability: Low stock: 10 left

SKU: 51304485-150 MC-PDIX02
Vendor: Honeywell
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Honeywell MC-PDIX02 (51304485-150) is a high-density Digital Input Processor module designed for integration within the Fault Tolerant Ethernet (FTE) and FSC (Fail Safe Controller) systems. This module provides 32 digital input channels, enabling reliable monitoring of field-side signals in critical industrial control environments. This specific unit features conformally coated circuitry to enhance durability and performance in harsh or corrosive operating conditions.

Features

  • 32-channel digital input capacity for high-density signal processing.
  • Conformally coated PCB assembly for improved environmental protection.
  • Supports 24 VDC input signal levels.
  • Galvanic isolation rated at 1500 VAC RMS or 1500 VDC to protect controller hardware from field-side transients.
  • Designed for robust operation within Honeywell FSC safety systems.

Technical Specifications

Manufacturer Honeywell
Model / Part Number MC-PDIX02 / 51304485-150
Input Channels 32
Input Voltage Range 20 - 30 VDC
Pick-Up Voltage (ON) 20 VDC minimum
Drop-Out Voltage (OFF) 10 VDC maximum
Sense Current (ON) 4.5 mA minimum
Sense Current (OFF) 2.8 mA maximum
Isolation 1500 VAC RMS / 1500 VDC
Frequency Response DC to 15 Hz

Installation Guidelines

  • Ensure all power to the chassis is disconnected before inserting or removing the module to prevent damage to the backplane connectors.
  • Verify that the module is fully seated in the designated slot and that the locking mechanisms are engaged.
  • Use appropriate grounding practices to minimize EMI/RFI interference in the control cabinet.
  • Maintain proper ventilation within the enclosure; ensure that air intake and exhaust paths are not obstructed by cable bundles.
  • Handle with care to avoid electrostatic discharge (ESD) during installation or maintenance.

FAQ

What is the primary function of the MC-PDIX02 module?

The MC-PDIX02 is a digital input processor module used in Honeywell safety control systems to monitor up to 32 discrete digital signals from field devices, converting them into a format understood by the controller.

Does this module require specific environmental considerations?

Yes, this unit features conformal coating, which provides a protective layer against humidity, dust, and chemical contaminants, making it suitable for demanding industrial environments.

Is this module compatible with standard 24 VDC field signals?

The module is designed for a 20-30 VDC operating range, making it compatible with standard 24 VDC industrial digital sensors and switches.
