Honeywell 8C-PAONA1 51454469-175 Analog Output Module

Honeywell 8C-PAONA1 51454469-175 Analog Output Module

Description

The Honeywell 8C-PAONA1 (51454469-175) is a high-performance Analog Output Module designed for the Experion LX control system. This module provides 16 channels of analog output, specifically engineered for precision control...

22 people are viewing this right now

Availability: Low stock: 1 left

SKU: 8C-PAONA1
Vendor: Honeywell
Category: Analog Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Honeywell 8C-PAONA1 (51454469-175) is a high-performance Analog Output Module designed for the Experion LX control system. This module provides 16 channels of analog output, specifically engineered for precision control in industrial automation environments. It supports configurable fail-safe behaviors on a per-channel basis, ensuring robust process integrity during system faults or communication losses.

Features

  • 16-channel analog output capability (4-20 mA).
  • Extensive integrated self-diagnostics for improved system reliability.
  • Supports optional redundancy configurations for critical control loops.
  • Configurable safe-state (FAILOPT) behaviors for each individual channel.
  • High resolution and linearity for precise process control.

Technical Specifications

Model 8C-PAONA1 / 51454469-175
Output Type 4-20 mA
Channels 16
Voltage Rating 24 VDC
Module Current Rating 190 mA
Load Resistance 50-800 Ohm
Output Current Linearity +/- 0.05% of Full Scale nominal
Resolution +/- 0.05% of Full Scale
Output Ripple <100 mV peak-to-peak at power line frequency
Temperature Drift 0.005% of Full Scale/degC
Output Range 2.9 mA to 21.1 mA
Max Open Circuit Voltage 22 V

Installation Guidelines

  • Ensure the control system is powered down before inserting or removing the module from the I/O rack.
  • Handle the module using ESD-safe practices to prevent damage to sensitive internal circuitry.
  • Verify that the module is fully seated in the rack slot and that the locking mechanism is engaged.
  • Ensure proper grounding of the I/O cabinet to minimize electromagnetic interference (EMI).
  • Use shielded twisted-pair cabling for analog signals to maintain signal integrity and reduce noise.
  • Route signal cables away from high-voltage power lines and high-EMI sources.

FAQ

Does this module support HART communication?

No, the 8C-PAONA1 is a non-HART analog output module.

Can this module be used in redundant configurations?

Yes, this module supports optional redundancy, allowing for high-availability control strategies when implemented with compatible Experion LX hardware.

What is the configurable safe-state behavior?

The module allows for per-channel configuration of fail-safe (FAILOPT) behaviors, enabling the user to define the output state (e.g., hold last value or drive to a specific current) in the event of a system failure.
