Honeywell 8C-SDOX01 51307051-175 Digital Output Relay Extension Board

Honeywell 8C-SDOX01 51307051-175 Digital Output Relay Extension Board

Description

The Honeywell 8C-SDOX01 (51307051-175) is a Digital Output (DO) Relay Extension Board designed for the Experion LX control system. This module provides reliable interface capabilities for field devices, offering galvanic...

18 people are viewing this right now

Availability: Low stock: 9 left

SKU: 8C-SDOX01
Vendor: Honeywell
Category: Digital Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Honeywell 8C-SDOX01 (51307051-175) is a Digital Output (DO) Relay Extension Board designed for the Experion LX control system. This module provides reliable interface capabilities for field devices, offering galvanic isolation and isolated dry contact outputs to ensure signal integrity and protection for the control system. It is engineered to handle inductive loads effectively through integrated counter-EMF snubbing circuits.

Features

  • Galvanic isolation between field signals and control logic.
  • Isolated dry contact outputs for flexible field device interfacing.
  • Integrated counter-EMF snubbing circuitry to protect relay contacts from inductive kickback.
  • Individual LED status indicators for each channel to verify the ON condition.
  • Robust contact material (Au over AgSnO2) for reliable switching performance.

Technical Specifications

Model Number 8C-SDOX01 / 51307051-175
Contact Type Au over AgSnO2
Maximum Load Voltage 250 VAC (RMS) / 125 VDC
Minimum Load Voltage 5 VDC
Minimum Load Current 10 mA or 100 mA
Maximum Inrush Current 10 A for 4s (10% duty cycle)
Voltage Rating 24 VDC
Module Current Rating 1010 mA
Isolation Rating 1500 VAC RMS or +/- 1500 VDC

Installation Guidelines

  • Ensure the control system is powered down before installing or removing the module from the rack.
  • Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to internal components.
  • Verify that field wiring is routed away from high-EMI sources, such as high-voltage power lines or variable frequency drives, to prevent signal interference.
  • Ensure all terminal connections are secure and that the module is fully seated in the designated backplane slot.
  • Check that the load requirements do not exceed the specified maximum voltage and current ratings to prevent relay failure.

FAQ

What is the primary function of the 8C-SDOX01 module?

The 8C-SDOX01 acts as a relay extension board for the Honeywell Experion LX system, providing isolated dry contact outputs to drive external field devices while protecting the controller from electrical noise and surges.

Does this module require external power?

The module is rated for 24 VDC operation; please refer to your specific Experion LX system documentation for proper power distribution and loop wiring requirements.
