Honeywell CC-IP0101 51410056-175 PROFIBUS DP Gateway Module

Honeywell CC-IP0101 51410056-175 PROFIBUS DP Gateway Module

The Honeywell CC-IP0101 (51410056-175) is a high-performance PROFIBUS DP Gateway Module (PGM) engineered for integration within Honeywell Experion PKS and Experion LX control systems. Designed in the Series 8 form...

16 people are viewing this right now

Availability: Low stock: 6 left

SKU: CC-IP0101
Vendor: Honeywell
Category: PROFIBUS Gateway Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Honeywell CC-IP0101 (51410056-175) is a high-performance PROFIBUS DP Gateway Module (PGM) engineered for integration within Honeywell Experion PKS and Experion LX control systems. Designed in the Series 8 form factor, this module acts as a master on the PROFIBUS network, facilitating robust data communication between the C300 controller and various field devices, including sensors, actuators, and motor drives.

Features

  • Supports module-level redundancy for high-availability applications.
  • Enables Removal and Insertion Under Power (RIUP) for maintenance without system downtime.
  • Integrated support for Experion events, alarms, and bulk build utilities.
  • Provides data filtering capabilities to optimize network traffic and prevent congestion.
  • Equipped with reverse voltage protection and high EMI/RFI resistance for signal stability.
  • Supports two independent PROFIBUS DP networks per module.

Applications

  • Oil and Gas: Refineries, LNG terminals, and offshore drilling platforms.
  • Petrochemicals: Continuous production facilities for aromatics and fertilizers.
  • Power Generation: Thermal power plants and nuclear auxiliary control systems.
  • Industrial Manufacturing: Large-scale paper machines and metallurgical cooling systems.

Technical Specifications

Model CC-IP0101 (51410056-175)
Operating Voltage 24 V DC (±10%)
Current Consumption 150 mA (idle) to 500 mA (full load)
Max Nodes 125 nodes per segment
Operating Temperature -20 degC to +60 degC
Storage Temperature -40 degC to +85 degC
Humidity 5% to 95% RH (non-condensing)
Isolation 500 V AC
Connector Type 9-pin D-sub or terminal block

Installation Guidelines

  • Ensure the module is mounted onto the appropriate Series 8 Input Output Termination Assembly (IOTA).
  • Verify that the 24V DC power supply is within the specified range before connection.
  • Maintain proper grounding practices as defined for Series 8 components to ensure EMI protection.
  • Always power down the IOTA or follow site-specific RIUP procedures before physical module removal.
  • Route communication cables away from high-voltage power lines to minimize electromagnetic interference.

FAQ

What is the primary role of the CC-IP0101?

The CC-IP0101 serves as a PROFIBUS DP master, bridging fieldbus-compatible devices with the Honeywell C300 controller environment.

Does this module support redundancy?

Yes, the module supports optional module-level redundancy to ensure continuous operation in critical control loops.

Can this module be hot-swapped?

Yes, it supports Removal and Insertion Under Power (RIUP), allowing for replacement while the system remains operational.

How many devices can be connected?

The module can manage communication with up to 127 PROFIBUS DP slave devices.
