The Honeywell TC-IAH061 is a high-performance analog input module within the Experion PKS Series-A I/O family. It acquires precise signals from high-level field instruments such as pressure transmitters,...
Availability: Low stock: 50 left
Reliable Worldwide Delivery
30-Day Money-Back Guarantee
Need more details? Read our fullShipping PolicyandRefund Policy.
The Honeywell TC-IAH061 is a high-performance analog input module within the Experion PKS Series-A I/O family. It acquires precise signals from high-level field instruments such as pressure transmitters, flow meters, and temperature sensors. With six galvanically isolated channels, the module ensures reliable data acquisition while protecting the control system from electrical interference and field-side disturbances.
| Parameter | Details |
|---|---|
| Model Number | TC-IAH061 |
| Condition | 100% Brand New Original |
| Input Channels | 6 (Galvanically Isolated) |
| Module Update Rate | 25 ms (all channels synchronized) |
| Open Circuit Detection | Upscale (Voltage), Zero scale (Current) |
| OC Detection Time | 5 s (Voltage), 1 s (Current) |
| Channel Bandwidth | 0–15 Hz (-3 dB) |
| RFI Immunity | < 2.0% error @ 10 V/m (27–1000 MHz) |
| Power Dissipation | 4.3 W (max) |
| Terminal Block Requirement | TC-TBNH (20-position) |
High-Level Signal Acquisition
Accurately processes inputs from transmitters such as pressure, flow, and temperature devices.
Channel-Level Galvanic Isolation
Prevents ground loops and protects the controller from voltage surges and electrical faults.
Fast Synchronized Updates
25 ms update rate across all channels enables responsive control for dynamic process environments.
Built-In Diagnostics
Open-circuit detection quickly identifies wiring faults, distinguishing them from process anomalies.
Strong RFI Immunity
Maintains measurement accuracy in environments with high electromagnetic interference.
Low Power Consumption
Minimal heat generation improves overall cabinet reliability and component lifespan.
Is this TC-IAH061 a brand new original module?
Yes, it is supplied as 100% brand new, original Honeywell hardware in factory-sealed packaging.
Which terminal block is required?
It uses the TC-TBNH 20-position terminal block for field wiring connections.
How does it detect wiring faults?
It detects open circuits and provides upscale readings for voltage inputs and zero-scale readings for current loops within defined detection times.
Is it suitable for harsh industrial environments?
Yes, it is designed for industrial use with vibration resistance, galvanic isolation, and strong RFI immunity, making it suitable for demanding applications.
