Horizontal Bus Driver Module 10100/2/1 Honeywell

Horizontal Bus Driver Module 10100/2/1 Honeywell

Product Overview

The Honeywell 10100/2/1 serves as a Horizontal Bus Driver (HBD) within the Fail-Safe Control (FSC) system. This module acts as the critical interface between the vertical bus and the horizontal I/O backplane, ensuring high-speed...

17 people are viewing this right now

Availability: Low stock: 50 left

SKU: 10100/2/1
Vendor: Honeywell
Category: Horizontal Bus Driver Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The Honeywell 10100/2/1 serves as a Horizontal Bus Driver (HBD) within the Fail-Safe Control (FSC) system. This module acts as the critical interface between the vertical bus and the horizontal I/O backplane, ensuring high-speed communication across the rack. It manages data synchronization and power distribution, maintaining the deterministic performance required for certified safety-instrumented systems. We supply this unit as 100% brand new, original factory stock to guarantee system stability and reliable operation.

Technical Specifications

Specification Details
Model Number 10100/2/1
Module Type Horizontal Bus Driver (HBD)
Power Requirements With A1/A21 Cable: 5 VDC, 35 mA

With A22 Cable: 5 VDC, 65 mA
Ripple Content < 50 mV p-p
Weight 0.11 kg
Condition 100% Brand New, Original

Engineering Advantages

  • Stable Signal Propagation: Ensures consistent signal strength across the horizontal backplane, preventing data skew and timing errors, especially in high-density I/O configurations.

  • Low-Noise Operation: With ripple content < 50 mV p-p, the module provides a clean power environment, shielding sensitive components from electromagnetic interference.

  • Efficient Power Footprint: The module draws as little as 35 mA, minimizing the thermal load on the power supply, extending the life of adjacent safety-critical modules.

  • Compact Integration: The 4 TE width allows for space-efficient installation, ensuring robust bus driving capabilities without taking up extra rack space.

FAQs

  • What is the difference between a Vertical and Horizontal Bus Driver?
    The Vertical Bus Driver (VBD) manages communication between different racks, while the Horizontal Bus Driver (HBD) drives signals within a single horizontal I/O rack.

  • How does the choice of cable affect the power requirements?
    Power consumption increases from 35 mA (A1/A21 cables) to 65 mA (A22 cables) due to additional electrical load needed to maintain signal integrity over longer cable types.

  • Is this module hot-swappable?
    No, this module should not be replaced while the system is powered. Removal during operation will disrupt communication with all I/O modules in the rack.

  • What diagnostics are available for the 10100/2/1?
    The module integrates with the FSC central diagnostic system. Any failure in bus synchronization or power regulation will be flagged as a fault in Honeywell Safety Builder.
