General Electric IC693DSM302 Series 90-30 Motion Mate Control Module

General Electric IC693DSM302 Series 90-30 Motion Mate Control Module

Description

The General Electric IC693DSM302 is a Motion Mate control module designed for the Series 90-30 Programmable Logic Controller (PLC) system. This specialized module provides high-performance motion control capabilities, allowing for...

17 people are viewing this right now

Availability: Low stock: 10 left

SKU: IC693DSM302
Vendor: General Electric
Category: Motion Control Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The General Electric IC693DSM302 is a Motion Mate control module designed for the Series 90-30 Programmable Logic Controller (PLC) system. This specialized module provides high-performance motion control capabilities, allowing for precise management of up to two axes of motion. It integrates seamlessly into the 90-30 backplane, enabling users to execute complex motion profiles directly from the PLC environment.

Features

  • Supports control for up to 2 independent axes.
  • Integrated RS-232 serial port for communication and configuration.
  • Non-volatile storage capacity for up to 10 programs and 40 subroutines.
  • Fast block processing time of less than 5 milliseconds.
  • High-resolution programming units for position, velocity, and acceleration control.

Technical Specifications

Product Model IC693DSM302
Manufacturer General Electric
Series Series 90-30
Axes Controlled 2
Backplane Current 450 mA at 5V DC
Position Resolution -8,388,608 to 8,388,607 user units
Velocity Resolution 1 to 8,388,607 user units/sec
Acceleration Resolution 1 to 134,217,727 user units/sec^2
Operating Temperature 0 to 60 degC
Storage Temperature -40 to 85 degC

Installation Guidelines

  • Ensure the PLC system power is disconnected before installing or removing the module from the backplane.
  • The module should be seated firmly in a standard Series 90-30 I/O rack slot.
  • Use shielded cables for RS-232 communication to minimize electromagnetic interference (EMI).
  • Maintain proper ventilation within the control cabinet to ensure the module operates within the specified 0 to 60 degC temperature range.
  • Follow standard ESD (Electrostatic Discharge) precautions when handling the module to prevent damage to internal circuitry.

FAQ

What is the primary function of the IC693DSM302?

The IC693DSM302 acts as a dedicated motion controller for GE 90-30 PLCs, offloading motion processing tasks from the main CPU to manage up to two axes with high precision.

How is this module powered?

The module draws its operating power directly from the PLC backplane, consuming approximately 450 mA at 5V DC.
