Description

The IC698CRE040 is a high-performance Central Processing Unit (CPU) module designed for the GE Fanuc PACSystems Rx7i control platform. Built around a 1.8 GHz Pentium M processor, this module serves as the primary controller for demanding industrial applications, including power generation, oil and gas processing, and large-scale manufacturing. It is engineered to handle complex logic, motion control, and high-speed data processing while maintaining low latency to maximize system uptime in critical distributed control environments.

Features

• Equipped with a 1.8 GHz Pentium M processor for high-speed logic execution.
• Includes 64 MB of user memory for extensive program storage and data logging.
• Dual RJ45 Ethernet ports supporting 10/100 Mbps auto-negotiation and EGD (Ethernet Global Data) communication.
• Dual serial interfaces supporting RS-232 and RS-485 protocols for legacy device connectivity.
• Supports up to 16 simultaneous web and FTP connections for real-time monitoring.
• High-precision internal timing with minimal drift for synchronized operation in redundant systems.

Applications

This CPU module is suitable for use in high-availability industrial automation systems, including:

• Large-scale power generation facilities.
• Oil refining and petrochemical processing plants.
• Deep-pit mining operations requiring robust motion and logic control.
• Distributed control systems (DCS) requiring multi-protocol communication.

Technical Specifications

Installation Guidelines

• Ensure the PACSystems Rx7i rack is powered down before inserting or removing the CPU module to prevent electrical damage.
• Handle the module using proper ESD (electrostatic discharge) precautions to protect internal circuitry.
• Ensure the module is fully seated in the designated slot and secured with the integrated locking mechanism.
• Route communication cables away from high-voltage power lines and sources of electromagnetic interference (EMI) to maintain signal integrity.
• Verify that the ventilation path is clear to allow for proper heat dissipation within the operating temperature range.

FAQ

What is the primary function of the IC698CRE040?

The IC698CRE040 acts as the central processor for the PACSystems Rx7i system, managing logic execution, data logging, and communication between field devices and the control network.

Does this module support redundant configurations?

Yes, the module is designed to support synchronized operation, making it suitable for redundant system architectures where high availability is required.

What type of memory does this CPU utilize?

The module features 64 MB of user memory, which is utilized for storing logic programs, configuration data, and system logs.
