ICS Triplex T8461 TMR 24/48V Digital Output Module

ICS Triplex T8461 TMR 24/48V Digital Output Module

Product Description

The T8461 is a high-integrity digital output module for the ICS Triplex Trusted Triple Modular Redundant (TMR) platform. Designed for critical control applications requiring SIL 3 safety compliance, it features a...

27 people are viewing this right now

Availability: Low stock: 10 left

SKU: T8461
Vendor: ICS Triplex
Category: Digital Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The T8461 is a high-integrity digital output module for the ICS Triplex Trusted Triple Modular Redundant (TMR) platform. Designed for critical control applications requiring SIL 3 safety compliance, it features a fault-tolerant architecture with three independent sub-modules that vote on output states. This ensures that a single hardware failure cannot trigger a spurious trip or compromise safety functions.

Supporting both 24 Vdc and 48 Vdc outputs, the T8461 is suitable for a wide range of industrial safety loops, including solenoids, relays, and motor starters.

Detailed Technical Specifications

Parameter Specification
Model Designation T8461
System Platform Trusted TMR Safety System
Output Type 40 isolated digital output channels
Operating Voltage 24–48 Vdc nominal
Redundancy Architecture Triple Modular Redundant (TMR) with 2oo3 internal voting
Safety Rating SIL 3 compliant
Output Current Optimized for solenoid valves, relays, and motor starters
Diagnostics Continuous self-testing of outputs and load integrity
Short Circuit Protection Per-channel electronic current limiting
Dimensions 39 cm × 31 cm × 9 cm
Weight 1.7 kg

Industrial Application Scenarios

The T8461 is widely deployed in high-reliability safety-critical environments, including:

  • Emergency Shutdown (ESD) systems

  • Fire & Gas (F&G) detection systems

  • Burner Management Systems (BMS)

  • Offshore oil platforms, nuclear power plants, and chemical processing facilities

Its ability to handle 48 Vdc outputs makes it ideal for long-distance field wiring and upgrades to legacy infrastructure.

Technical FAQs

How does the TMR voting work in this module?
The T8461 employs a "Two-out-of-Three" (2oo3) hardware voting scheme. Even if one internal processing path fails, the output maintains the correct state, allowing online repair without interrupting operations.

Does it support line monitoring?
Yes. The module can detect both open circuits and short circuits in field wiring, providing detailed diagnostic feedback to the Trusted controller for rapid troubleshooting.
