GE Fanuc IS200TBTCH1C Mark VIe Thermocouple Input Terminal Board

GE Fanuc IS200TBTCH1C Mark VIe Thermocouple Input Terminal Board

Description

The IS200TBTCH1C is a high-density Thermocouple Input Terminal Board designed for the General Electric Mark VIe distributed control system. This board serves as the primary interface between field-mounted thermocouple sensors...

25 people are viewing this right now

Availability: Low stock: 7 left

SKU: IS200TBTCH1C
Vendor: GE FANUC
Category: Terminal Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The IS200TBTCH1C is a high-density Thermocouple Input Terminal Board designed for the General Electric Mark VIe distributed control system. This board serves as the primary interface between field-mounted thermocouple sensors and the system's I/O processor packs. It is engineered to support mission-critical turbine control applications, providing reliable signal acquisition for 24 independent channels. The board is compatible with multiple thermocouple types, including E, J, K, S, and T, and supports flexible system architectures ranging from simplex to triple modular redundant (TMR) configurations.

Features

  • Supports 24 independent thermocouple input channels.
  • Compatible with thermocouple types E, J, K, S, and T.
  • Direct interface for PTCC I/O packs via onboard J-type connectors.
  • Supports Simplex, Dual, and TMR system configurations.
  • Integrated shield terminal strips for improved noise immunity and signal integrity.
  • Accommodates field wiring up to 12 AWG via barrier-type terminal blocks.

Applications

The IS200TBTCH1C is specifically designed for use in GE Mark VIe control systems, primarily found in power generation, turbine control, and heavy industrial process monitoring where high-precision temperature measurement and system redundancy are required.

Technical Specifications

Model IS200TBTCH1C
Series Mark VIe
Input Channels 24
Supported Thermocouples E, J, K, S, T
Input Span -8 mV to +45 mV
Operating Temperature 0 to 45 deg C
Wiring Capacity Up to 12 AWG
System Compatibility PTCC I/O Packs

Installation Guidelines

  • Ensure the control system power is disconnected before installing or removing the terminal board or associated I/O packs.
  • Mount the board securely within the designated Mark VIe cabinet rack.
  • Utilize the dedicated shield terminal strips on the left side of the terminal blocks to ground cable shields, reducing the risk of electromagnetic interference (EMI).
  • Ensure proper seating of PTCC I/O packs into the board connectors to maintain reliable signal path continuity.
  • Maintain ambient operating temperatures within the specified 0 to 45 deg C range to ensure long-term component reliability.

FAQ

Is the IS200TBTCH1C compatible with all Mark VIe I/O packs?

This board is specifically designed to interface with PTCC I/O packs. Please verify your specific system configuration and I/O pack requirements before installation.

Does this board support TMR configurations?

Yes, the IS200TBTCH1C is engineered to support Simplex, Dual, and Triple Modular Redundant (TMR) configurations, allowing for high-availability control architectures.
