ProSoft MVI56-CSC ASCII Serial Communication Module

ProSoft MVI56-CSC ASCII Serial Communication Module

Description

The ProSoft MVI56-CSC is a high-performance ASCII Serial Communication Module designed for seamless integration with Rockwell Automation ControlLogix platforms. This module provides two fully isolated serial ports, allowing the ControlLogix...

28 people are viewing this right now

Availability: Low stock: 7 left

SKU: MVI56-CSC
Vendor: ProSoft
Category: Communication Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ProSoft MVI56-CSC is a high-performance ASCII Serial Communication Module designed for seamless integration with Rockwell Automation ControlLogix platforms. This module provides two fully isolated serial ports, allowing the ControlLogix processor to interface with a wide range of ASCII-based devices such as barcode scanners, weigh scales, printers, and terminal blocks. By offloading serial communication tasks from the main processor, the MVI56-CSC enhances overall system efficiency and simplifies data exchange in industrial automation environments.

Features

  • Dual isolated serial ports for robust communication.
  • Supports RS-232, RS-422, and RS-485 physical interfaces.
  • Configurable baud rates from 300 to 115,200 bit/s.
  • Direct backplane communication with ControlLogix processors.
  • Supports complex ASCII string handling and data parsing.
  • LED status indicators for module health and port activity.

Technical Specifications

Product Model MVI56-CSC
Manufacturer ProSoft
Isolation 500 VDC
Baud Rate 300 – 115,200 bit/s
Operating Temperature 0 degC to +60 degC
Storage Temperature -40 degC to +85 degC
Humidity 5 – 95 % RH (non-condensing)

Installation Guidelines

  • Ensure the ControlLogix rack is powered down before inserting or removing the module.
  • Slide the module into any available slot in the ControlLogix chassis and secure it using the top and bottom locking tabs.
  • Use shielded communication cables to minimize electromagnetic interference (EMI) in high-noise industrial environments.
  • Ensure proper grounding of the serial cable shields at the device end to prevent ground loops.
  • Verify that the serial interface configuration (RS-232/422/485) matches the requirements of the connected field device.

FAQ

What type of devices can connect to the MVI56-CSC?

The module is designed to communicate with any ASCII-based serial device, including barcode scanners, weigh scales, LED marquees, and legacy serial instrumentation.

Does this module require external power?

No, the MVI56-CSC draws its power directly from the ControlLogix backplane.
