Ovation 1X00102H01 Analog Input Module

Ovation 1X00102H01 Analog Input Module

Description

The Ovation 1X00102H01 is a high-precision 16-channel analog input module engineered for integration within Westinghouse/WDPF distributed control systems. This module provides essential signal conditioning and data acquisition for industrial processes,...

17 people are viewing this right now

Availability: In stock

SKU: 1X00102H01
Vendor: Ovation
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Ovation 1X00102H01 is a high-precision 16-channel analog input module engineered for integration within Westinghouse/WDPF distributed control systems. This module provides essential signal conditioning and data acquisition for industrial processes, converting field analog signals into high-resolution digital data for real-time monitoring and control. It is designed to maintain systemic stability in mission-critical environments by ensuring accurate signal processing and reducing diagnostic latency.

Features

  • 16 single-ended analog input channels.
  • 16-bit resolution for high-fidelity process variable measurement.
  • Direct interface with the proprietary WDPF control bus.
  • Localized signal processing for I/O scaling and filtering.
  • Robust design for high immunity against electromagnetic interference (EMI).
  • Supports hot-swappable replacement in compatible rack configurations.

Applications

This module is widely utilized in power generation facilities and large-scale industrial manufacturing plants where reliable, high-speed analog data acquisition is required for process stability and safety.

Technical Specifications

Model 1X00102H01
Brand Ovation
Channel Count 16
Resolution 16-bit
Operating Temperature 0 to 60 deg C

Installation Guidelines

  • Ensure the control system power is disconnected before installing or removing the module from the rack.
  • Handle the module using proper ESD (Electrostatic Discharge) mitigation techniques to prevent component damage.
  • Verify that the module is fully seated in the backplane to ensure reliable communication with the WDPF bus.
  • Route analog signal cabling away from high-voltage power lines and high-EMI sources to maintain signal integrity.
  • Ensure adequate ventilation within the cabinet to maintain the operating temperature within the specified 0 to 60 deg C range.

FAQ

Is this module compatible with all WDPF systems?
The 1X00102H01 is designed for specific WDPF architectures. Please verify your system's hardware revision and compatibility requirements before installation.

Does this module support hot-swapping?
Yes, the module supports hot-swappable replacement provided the host rack and system software configuration support this functionality.
