PCU2000ETH V4.5.0 Ethernet Card WOODWARD

PCU2000ETH V4.5.0 Ethernet Card WOODWARD

The WOODWARD PCU2000ETH V4.5.0, also cataloged as the PCU2000ETH V4.5.0 Ethernet Card, operates as a dedicated hardware component for high-speed network communication and serial protocol offloading within PC-based SCADA and...

19 people are viewing this right now

Availability: Low stock: 6 left

SKU: PCU2000ETH V4.5.0
Vendor: Woodward
Category: Ethernet Card
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The WOODWARD PCU2000ETH V4.5.0, also cataloged as the PCU2000ETH V4.5.0 Ethernet Card, operates as a dedicated hardware component for high-speed network communication and serial protocol offloading within PC-based SCADA and HMI automation platforms.

Hardware Specifications

Parameter Specification
Model PCU2000ETH V4.5.0
Brand WOODWARD
Origin USA
Weight 0.14 kg (0.31 lbs)
Dimensions Standard PCI Half-Length Card
Operating Temp 0 to 60 deg C
Power Consumption 3.3 VDC / 5 VDC via PCI slot
Processor AMD SC520 @ 133 MHz
Onboard Memory 16 MB SDRAM, 128 KB SRAM, 4 MB Flash
Ethernet Interface 10/100 Mbps Fast Ethernet (RJ-45)
Serial Interface 1-Channel Isolated RS-485 / RS-422
Bus Interface Universal PCI (3.3 V / 5 V signaling)
Software Interfaces OPC, DLL, DAS drivers

Protocol Conversion Latencies and Deterministic Ethernet Networking

The onboard 133 MHz AMD SC520 processor offloads network protocol stacks directly from the host PC CPU. Running dedicated OPC, DLL, or DAS communication drivers across the 10/100 Mbps Ethernet link and RS-485/RS-422 serial interface minimizes protocol conversion latencies. This dedicated onboard memory structure (16 MB SDRAM, 128 KB SRAM, and 4 MB Flash) guarantees real-time buffer management and deterministic data transfer between field controllers and SCADA/HMI nodes.

Frequently Asked Questions

Q: Does the PCU2000ETH V4.5.0 support hot-swapping inside an active host PC?

A: No. The card installs directly into standard 3.3 V or 5 V Universal PCI expansion slots. Power down the host computer chassis before inserting or removing the PCI card to avoid damaging the bus interface.

Q: How is signal isolation managed on the onboard serial channel?

A: The single-channel RS-485/RS-422 interface features galvanic isolation designed to break ground loops and prevent common-mode voltage spikes from reaching the host PCI bus.

Field Installation Guidelines

  1. Power off the host PC chassis and disconnect main AC power feeds prior to opening the expansion bay.
  2. Seat the PCI card firmly into a compatible 3.3 V or 5 V Universal PCI bus slot until the retaining bracket aligns with the frame.
  3. Fasten the metal retaining bracket screw to verify solid chassis grounding and structural stability.
  4. Route Ethernet RJ-45 lines and twisted-shielded RS-485/RS-422 cables away from high-voltage AC power wiring to prevent noise coupling.
  5. Ensure internal cabinet fan airflow maintains ambient temperatures below 60 deg C around the PCI card slot area.
