ProSoft 3100-MCM Modbus Master/Slave Communication Module

ProSoft 3100-MCM Modbus Master/Slave Communication Module

Description

The ProSoft 3100-MCM is a high-performance Modbus Master/Slave communication interface module designed specifically for the Allen-Bradley PLC-5 platform. Operating as a single-slot backplane component, this module facilitates seamless data exchange...

22 people are viewing this right now

Availability: Low stock: 8 left

SKU: 3100-MCM
Vendor: Prosoft
Category: Communication Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ProSoft 3100-MCM is a high-performance Modbus Master/Slave communication interface module designed specifically for the Allen-Bradley PLC-5 platform. Operating as a single-slot backplane component, this module facilitates seamless data exchange between the PLC processor and external Modbus-compatible devices, including power monitors, motor drives, and specialized field sensors. It is a critical component for legacy system integration, enabling the centralization of field data to enhance diagnostic capabilities and reduce operational downtime in industrial environments such as oil refineries, power generation, and mining.

Features

  • Dual Port Configuration: Features two independent serial ports, each independently configurable as a Modbus Master or Modbus Slave, allowing for simultaneous polling of field instruments and communication with supervisory SCADA systems.
  • Protocol Support: Supports both Modbus RTU and ASCII modes. Master mode supports extensive command control including function codes 1, 2, 3, 4, 5, 6, 15, and 16.
  • Data Integrity: Implements hardware-level parity checking and CRC/LRC error detection to ensure reliable data transmission across long-distance RS-485 or RS-422 cabling.
  • Backplane Integration: Designed for direct integration into the PLC-5 chassis, utilizing the backplane for both power and high-speed data bus interfacing.

Applications

The 3100-MCM is widely utilized in industrial automation for connecting legacy PLC-5 systems to modern Modbus-enabled field devices. Typical applications include monitoring energy usage via power meters, controlling variable frequency drives (VFDs), and integrating remote I/O or specialized sensors into the primary control network.

Technical Specifications

Model 3100-MCM
Brand ProSoft Technology
Backplane Current Draw 0.5 A at 5 VDC
Communication Ports 2 Serial Ports (RS-232, RS-422, or RS-485)
Baud Rates 300 to 19,200 bps
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 85 deg C
Relative Humidity 5% to 95% (Non-condensing)
Compatibility Allen-Bradley PLC-5 /11, /20, /25, /30, /40, /60

Installation Guidelines

  • Ensure the PLC-5 chassis is powered down before inserting or removing the module to prevent electrical damage.
  • The module must be seated firmly in the backplane slot to ensure proper power and data connection.
  • Use shielded twisted-pair cabling for RS-485/422 connections to minimize EMI interference in industrial environments.
  • Ensure proper grounding of the cable shields at one end to prevent ground loops.
  • Maintain adequate ventilation around the PLC-5 chassis to ensure the module operates within the specified 0 to 60 deg C temperature range.

FAQ

Is the 3100-MCM compatible with all PLC-5 processors?

The module is compatible with standard PLC-5 models including the /11, /20, /25, /30, /40, and /60 series. Please verify your specific processor firmware and chassis slot availability before installation.

Can both ports be used simultaneously?

Yes, the 3100-MCM features two independent serial ports that can be configured separately to act as either a Modbus Master or a Modbus Slave, allowing for simultaneous communication with different field devices.
