ProSoft MVI69-MCM Modbus Master/Slave Communication Module for CompactLogix

ProSoft MVI69-MCM Modbus Master/Slave Communication Module for CompactLogix

Description

The ProSoft MVI69-MCM is a high-performance Modbus Master/Slave communication module designed specifically for the Rockwell Automation CompactLogix platform. This single-slot module enables seamless integration of Modbus-enabled devices into a ControlLogix...

27 people are viewing this right now

Availability: Low stock: 3 left

SKU: MVI69-MCM
Vendor: ProSoft
Category: Communication Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ProSoft MVI69-MCM is a high-performance Modbus Master/Slave communication module designed specifically for the Rockwell Automation CompactLogix platform. This single-slot module enables seamless integration of Modbus-enabled devices into a ControlLogix or CompactLogix architecture, acting as a bridge between the PLC and external serial devices such as drives, sensors, and instrumentation.

Features

  • Compatible with Rockwell Automation CompactLogix systems.
  • Supports both Modbus Master and Slave configurations for flexible network integration.
  • Data transfer managed via standard ladder logic for simplified programming.
  • Supports baud rates ranging from 110 to 115K baud.
  • Configurable node addressing from 1 to 247.
  • Standard 1769 single-slot form factor for easy backplane mounting.

Applications

This module is widely used in industrial automation environments requiring serial communication, including water and wastewater treatment, oil and gas processing, power generation, and general manufacturing where legacy Modbus devices must interface with modern Allen-Bradley controllers.

Technical Specifications

Product Model MVI69-MCM
Compatibility CompactLogix (1769)
Slot Requirement Single-slot
Current Load 800 mA max. @ 5 VDC
Baud Rate 110 - 115K baud
Supported Protocols Modbus Master/Slave
Node Address Range 1 - 247

Installation Guidelines

  • Ensure the CompactLogix system power is disconnected before installing or removing the module.
  • Slide the MVI69-MCM into the designated 1769 chassis slot and secure it using the integrated locking mechanism.
  • Use shielded twisted-pair cabling for serial connections to minimize EMI interference in high-noise industrial environments.
  • Verify that the module is properly seated in the backplane to ensure reliable communication with the CPU.
  • Configure the module parameters using the appropriate ProSoft configuration software or ladder logic integration files.

FAQ

Q: Is this module compatible with all CompactLogix processors?
A: The MVI69-MCM is designed for the 1769 CompactLogix platform. Please verify your specific processor firmware and backplane compatibility before installation.

Q: How is data transferred between the module and the PLC?
A: Data transfer is handled via ladder logic, allowing the PLC to read and write Modbus registers directly through the module's memory mapping.
