GE Fanuc QPICTAE0000 QuickPanel Operator Interface Module

GE Fanuc QPICTAE0000 QuickPanel Operator Interface Module

Description

The QPICTAE0000 is a 10.4-inch industrial human-machine interface (HMI) from the GE Fanuc Total Control QuickPanel series. Designed for demanding environments such as power generation, mining, and oil refinery applications,...

18 people are viewing this right now

Availability: Low stock: 6 left

SKU: QPICTAE0000
Vendor: GE FANUC
Category: Operator Interface Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The QPICTAE0000 is a 10.4-inch industrial human-machine interface (HMI) from the GE Fanuc Total Control QuickPanel series. Designed for demanding environments such as power generation, mining, and oil refinery applications, this unit provides a robust, buttonless touch-screen interface. By utilizing a high-contrast TFT color display, the module enables operators to visualize complex diagnostic data and control processes efficiently. The device is built to minimize mechanical failure points by replacing physical buttons with a durable touch membrane, ensuring long-term reliability in industrial settings.

Features

  • Display Technology: 10.4-inch TFT color LCD with 640 x 480 VGA resolution.
  • Memory: 4 MB integrated Flash EPROM for application storage.
  • Connectivity: Includes a 10BaseT Ethernet port, dual serial ports, and a parallel printer port for local logging.
  • Auxiliary Interfaces: Supports external alarm monitoring, remote hardware reset, and integrated buzzer/audio output.
  • Environmental Protection: NEMA 4X/12 and IP65 rated enclosure, providing protection against dust and low-pressure water ingress.

Technical Specifications

Model QPICTAE0000
Display Size 10.4 inches
Resolution 640 x 480 Pixels (VGA)
Memory 4 MB Flash EPROM
Input Voltage 85 to 132 VAC (120 VAC nominal)
Frequency 47 to 63 Hz
Operating Temperature 0 to 50 deg C
Storage Temperature -20 to 60 deg C
Software QuickDesigner 3.7 or higher

Installation Guidelines

  • Powering: Ensure the supply voltage is within the 85-132 VAC range before connection. Always verify polarity and ground connections to prevent electrical damage.
  • Mounting: The unit is designed for panel mounting. Ensure the gasket is properly seated to maintain the NEMA 4X/IP65 seal against the enclosure surface.
  • Environment: Maintain adequate ventilation around the rear chassis to prevent heat buildup. Avoid installing in areas with excessive vibration or direct exposure to corrosive chemicals.
  • Handling: Use ESD-safe practices when handling the unit. Ensure the system is powered down before connecting or disconnecting communication cables.

FAQ

What software is required to program the QPICTAE0000?

This module requires QuickDesigner software, version 3.7 or higher, for project development and configuration.

Is this unit suitable for outdoor use?

The unit features an IP65/NEMA 4X rating, meaning it is dust-tight and protected against water jets. However, it is primarily intended for industrial control panels; please ensure it is installed in an appropriate enclosure if exposed to extreme weather conditions.

Can I connect a printer to this HMI?

Yes, the module includes a dedicated parallel printer port, allowing for the generation of local data logs and alarm reports directly from the interface.
