GE Fanuc IC694PWR330 RX3i PacSystem Power Supply Module

GE Fanuc IC694PWR330 RX3i PacSystem Power Supply Module

Description

The GE Fanuc IC694PWR330 is a high-performance power supply module designed for the RX3i PacSystem backplane. It provides reliable voltage regulation and power distribution, converting high-voltage inputs into stable logic-level...

20 people are viewing this right now

Availability: Low stock: 5 left

SKU: IC694PWR330
Vendor: GE FANUC
Category: Power Supply Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The GE Fanuc IC694PWR330 is a high-performance power supply module designed for the RX3i PacSystem backplane. It provides reliable voltage regulation and power distribution, converting high-voltage inputs into stable logic-level currents required for system operation. Engineered for demanding industrial environments, this module ensures consistent performance in sectors such as power generation, oil and gas, and heavy manufacturing. It features a 20 ms hold-up time to maintain controller operation during brief power sags or grid fluctuations, preventing unnecessary system resets.

Features

  • Universal input range supporting 85 to 264 VAC or 100 to 300 VDC.
  • Integrated 24 VDC auxiliary output loop (up to 20 W) for powering external field instrumentation.
  • Galvanic isolation of 1500 VAC to protect the backplane logic bus from field-side electrical transients.
  • Built-in overvoltage and overcurrent protection circuits for enhanced system safety.
  • Front-panel LED diagnostics (PWR, OK, RUN) for real-time status monitoring.

Technical Specifications

Model IC694PWR330
Series RX3i PacSystem
Input Voltage (AC) 85 to 264 VAC
Input Voltage (DC) 100 to 300 VDC
Output Power (Aux) 24 VDC (up to 20 W)
System Current Rating 2 A
Hold-up Time 20 ms minimum
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to +85 deg C
Humidity 5% to 95%, non-condensing

Installation Guidelines

  • Ensure the system power is disconnected before installing or removing the module from the RX3i rack.
  • Seat the module firmly into the backplane slot and secure the mounting screws to ensure proper grounding and mechanical stability.
  • Use appropriate wire gauges for power connections and tighten terminal screws to a torque of 1.3 N-m.
  • Maintain adequate clearance around the module to allow for proper airflow and cooling.
  • Avoid routing high-voltage power cables in the same conduits as low-voltage signal or communication wiring to minimize EMI.

FAQ

Does this module support both AC and DC input power?

Yes, the IC694PWR330 is designed to accept a wide range of inputs, specifically 85 to 264 VAC or 100 to 300 VDC.

What is the purpose of the auxiliary output?

The module provides an isolated 24 VDC output rated at 20 W, which is intended to power external field devices or instrumentation directly from the power supply.

How do I monitor the status of the power supply?

The module features three front-facing LED indicators: PWR (Power), OK (Module Health), and RUN (PLC Execution State), which provide immediate visual feedback on the operational status.
