Schneider BMXERT1604T Multifunction Input Module

Schneider BMXERT1604T Multifunction Input Module

Description

The Schneider BMXERT1604T is a high-performance multifunction input module designed for integration within Modicon M340 automation platforms. This versatile unit is engineered to consolidate mixed-signal processing by accepting a wide...

23 people are viewing this right now

Availability: Low stock: 10 left

SKU: BMXERT1604T
Vendor: Schneider
Category: Multifunction Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider BMXERT1604T is a high-performance multifunction input module designed for integration within Modicon M340 automation platforms. This versatile unit is engineered to consolidate mixed-signal processing by accepting a wide range of analog and digital inputs, effectively reducing the total module count required for complex control applications.

Features

  • 16 configurable channels providing high I/O density in a compact form factor.
  • Integrated support for multiple analog signal types including voltage (0-10V, +/-10V) and current (0-20mA, 4-20mA).
  • Comprehensive temperature measurement capabilities supporting various thermocouples (J, K, T, N, E, R, S, B) and RTD sensors (PT100, PT1000, Ni100, Ni1000).
  • Dedicated high-speed digital input channels capable of supporting counting frequencies up to 100 kHz for position feedback or pulse monitoring.
  • 16-bit analog-to-digital conversion for high-precision signal acquisition.

Technical Specifications

Analog Inputs 12 channels, 16-bit, multifunction
Digital Inputs 4 channels, 24V DC, high-speed
Input Types 0-10V, +/-10V, 0-20mA, 4-20mA, TC, RTD
Thermocouple Types J, K, T, N, E, R, S, B
RTD Types PT100, PT1000, Ni100, Ni1000
High-Speed Counts 100 kHz on dedicated digital channels
Update Rate 20 ms for all analog channels
Interface Type Single bus connector plus 28-position removable terminal

Installation Guidelines

  • Ensure the M340 rack is powered down before inserting or removing the module to prevent electrical damage.
  • Mount the module in a clean, dry environment with adequate ventilation to maintain operating temperature limits.
  • Use shielded cabling for all analog signal inputs to minimize electromagnetic interference (EMI) and ensure signal integrity.
  • Verify that the 28-position terminal block is securely seated and properly wired according to the specific channel configuration.
  • Handle the module using proper ESD (Electrostatic Discharge) precautions to protect internal circuitry.

FAQ

Q: Can the BMXERT1604T handle both RTD and thermocouple inputs simultaneously?
A: Yes, the module is designed for multifunctionality and can be configured to handle various analog signal types across its 12 analog channels.

Q: What is the maximum frequency for the high-speed digital inputs?
A: The dedicated high-speed digital channels support counting frequencies up to 100 kHz.
