Schneider Electric ASBDAP218 Advantys STB Output Module

Schneider Electric ASBDAP218 Advantys STB Output Module

Description

The Schneider Electric ASBDAP218 is a high-performance output module designed for the Advantys STB distributed I/O system. This module is engineered to control actuators, relays, and other industrial loads with...

23 people are viewing this right now

Availability: In stock

SKU: ASBDAP218
Vendor: Schneider
Category: Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Schneider Electric ASBDAP218 is a high-performance output module designed for the Advantys STB distributed I/O system. This module is engineered to control actuators, relays, and other industrial loads with high reliability. It features sixteen independent AC output channels, each providing electrical isolation to ensure safe and stable operation within complex automation environments.

Features

  • Sixteen independent AC output points.
  • Wide operating voltage range: 24 V AC to 230 V AC.
  • Continuous output current of 0.5 A per channel.
  • Integrated channel-to-channel and channel-to-bus electrical isolation.
  • Fail-safe design: outputs return to a safe off state automatically upon power loss.
  • Removable screw terminal block for efficient field wiring and maintenance.

Applications

This module is typically utilized in industrial automation systems for switching AC loads, controlling solenoid valves, motor starters, and contactors within the Schneider Advantys STB architecture.

Technical Specifications

Manufacturer Schneider Electric
Model ASBDAP218
Series Advantys STB
Number of Outputs 16 points
Output Voltage 24 V AC to 230 V AC
Output Current 0.5 A per channel
Isolation Yes (Channel-to-channel and channel-to-bus)
Wiring Interface Removable screw terminal block
Weight 0.3 kg

Installation Guidelines

  • Ensure the Advantys STB base is properly mounted on a DIN rail before installing the module.
  • Always disconnect power from the I/O system before inserting or removing the module to prevent electrical damage.
  • Use appropriate wire gauges for the screw terminal block to ensure secure connections.
  • Maintain proper grounding practices to minimize EMI/RFI interference in the control cabinet.
  • Ensure adequate ventilation around the module to prevent overheating during continuous operation.
  • Handle with care to avoid electrostatic discharge (ESD) damage to the internal PCB.

FAQ

Does this module require external power for the outputs?

Yes, the ASBDAP218 requires an external AC power source to drive the connected loads, as the module acts as a switching interface for the field devices.

What happens to the outputs if the communication bus fails?

The module is designed for safety; in the event of a loss of communication or power, the outputs will transition to a safe off state.
